- Page 1 HDbridge Advanced Configuration Manual Deploying Digital Signage Page | 1 The Case for Coax...
-
Page 2: Table Of Contents
Contents Getting Started with HDbridge ....................3 RF Rules Apply ........................... 3 Rack Chassis – RK1 or RK2 ......................3 Installing Modules in the Rack Chassis ..................3 Basic Configuration (Front Panel) ..................... 4 Channel Spacing ........................4 Unlocking the Setup Button ...................... 4 Setting the Channel via the Front Panel Button ............... -
Page 3: Getting Started With Hdbridge
Getting Started with HDbridge RF Rules Apply Treat the HDbridge system the same way as any other RF system. Each modulator (or “module”) outputs a QAM signal that works with off-the shelf RF tools, equipment, and materials. Each module requires a full RF channel. -
Page 4: Basic Configuration (Front Panel)
The LED will flash yellow twice per second FIVE times. There will be a two second pause. The LED will flash yellow twice per second TEN times. The LED will return to a steady blue. HDbridge™ Module Configuration Manual Page 4 www.zeevee.com Rev 1.0... -
Page 5: Changing Modulation Standards
The unit will then restore all factory defaults and go through a full reboot. Advanced Configuration Using WebManager For advanced configuration settings and/or remote access to the system, the HDbridge modules utilize the WebManager, a web interface available over an Ethernet connection either directly to a PC or through a switch/LAN connection. -
Page 6: Logging In To Webmanager
The default password is “admin” but it can be changed in the configuration tool (see page 8). NOTE: Login is case-sensitive. Navigating in WebManager Tabs across the top allow for different configuration and actions. HDbridge™ Module Configuration Manual Page 6 www.zeevee.com Rev 1.0... -
Page 7: Summary Tab
2. General status information. 3. Messages showing any errors or warnings WebManager has discovered. Configuration Tab The Navigation Bar on the left lists categories that link to a specific configuration section. HDbridge™ Module Configuration Manual Page 7 www.zeevee.com Rev 1.0... -
Page 8: Rf & Hdtv Channel
RF & HDTV Channel Configuration is where most changes typically occur. To change the RF and HDTV channel: 1. Enter the RF and HDTV channel the HDbridge module should use for broadcast. By default, they are linked – so if the RF Channel is 2, the HDTV channel will default to 2.1. -
Page 9: Rf & Hdtv Channel (Continued)
HDTV in “Guide” or “Info.” 3. Rating: Used to apply a “rating” to content, especially for use with tools like V-Chip. 4. Hit “Apply” to save your changes. HDbridge™ Module Configuration Manual Page 9 www.zeevee.com Rev 1.0... -
Page 10: Audio / Video
It can be set to “none” or to a specific input. 3. Idle Screen: Defaults to a bouncing ZeeVee logo. A new image can be uploaded to customize the idle screen for each channel. ... -
Page 11: Mpeg Encoding
IP address is set and you lose access because of the settings, you can reset it by using the pin on the back of the unit. Hit “Apply” to save your changes. HDbridge™ Module Configuration Manual Page 11 www.zeevee.com Rev 1.0... -
Page 12: Password Management
Password Management Since the HDbridge units can be accessed over a network, changing the password allows for added security. User Name is always “admin” the passwords can be set independently for each module. Resetting to defaults via WebManager or the reset pin on the back of the unit will change the password to “admin.”... -
Page 13: Audio/Video Status
Audio/Video Status 1. Input Video: Video source and the recognized format. 2. Output Video: Output video format will match the input. HDBridge modules do not scale. 3. Input Audio: Audio source, status, and format. 4. Output Audio: Audio output source and format. -
Page 14: Firmware Update Tab
2. Browse: Browse to the file on your local PC. 3. Upload & Install: Firmware will update and the module will reboot when finished. All settings are saved with the firmware update. HDbridge™ Module Configuration Manual Page 14 www.zeevee.com Rev 1.0... -
Page 15: Troubleshooting
You may be experiencing an RF power balance issue. Verify that the RF power of the modulator is balanced with signals from other modulators and from the cable company. Your HDTV may not be able to play the high data rate that the HDbridge module produces during fast action. Lower the data rate via the web interface.
