ZeeVee HDbridge 2000 Series Configuration Manual
Hide thumbs
Also See for HDbridge 2000 Series:
- Configuration manual (14 pages) ,
- Configuration manual (7 pages) ,
- Configuration manual (7 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for ZeeVee HDbridge 2000 Series
Summary of Contents for ZeeVee HDbridge 2000 Series
- Page 1 HDbridge 2920 C O N F I G U R A T I O N G U I D E S E R I E S...
-
Page 2: Table Of Contents
• HD-SDI Cable intended to alert the user to the presence of important Contact ZeeVee ..12 ditional components or accessories elsewhere defined to be used with the installation of the product, operating and maintenance (servicing) instructions in •... -
Page 3: Front And Back Panels
Front and Back Panels Basic Installation HD-SDI pass-through Analog HD-SDI to local monitor HD-SDI Audio (optional) Video Source Video Source RF Output +45 dBmV Back of HDb2920 Modulator Coax cable connects Optional Delay Matched ... -
Page 4: Front Panel Configuration
You can set the RF broadcast channels using the 494-502 654-662 814-822 • ZV channels can be set directly front panel controls. In many cases, your ZeeVee modulator will require only these configurations. adjacent to any other well-formed 502-510 662-670... -
Page 5: Maestro Configuration
THE AV SOURCE TAB Connecting with Maestro Allows you to specify audio 1. Connect your computer directly to the ZeeVee modulator and video sources as well as using a standard Ethernet cable (not a cross-over cable) or other configuration options for connect the unit and your computer to any LAN that has a the sources. -
Page 6: Troubleshooting
• Any ZeeVee Equipment that has been modified so the above limitation or exclusion may not apply Feed the audio to the ZeeVee unit and send it to the HDTV with the video. Then take the audio out from an HDTV or external ... -
Page 7: Declaration Of Conformity
+44 1494 956677 Phone Chromium, Cadmium, Polybromated Biphenyls, Polybromated Diphenyl Ether, Pentabromodiphenyl Ether, Octabromodiphenyl Ether, Decabromodiphenyl Ether. EMEAsales@zeevee.com Stephen Metzger Vice President of Engineering Direct all specific inquires to the ZeeVee, Inc. Engineering Department December 2014 Proudly designed and built in the USA...
