PHYSICAL SPECIFICATIONS
The following are physical specifications of the radiographic tables:
Models QT-740 & QT-750 - Service Manual
Quantum Medical Imaging
TABLETOP SPECIFICATIONS
Length:
Width:
Height (Model QT-740):
Height (Model QT-750):
Raised:
Lowered:
Tabletop Travel:
Longitudinal:
Lateral:
Tabletop Material:
Tabletop X-ray Density:
Tabletop-to-Film Plane
Distance:
*Note 1: To compensate for low ceilings, maximum raised table height can be
decreased by up to 2 inches less (see Assembly & Installation Chapter
for instructions)
TABLE BASE SPECIFICATIONS
Width:
Depth:
Maximum Patient Load (with
non-digital image receptor):
Maximum Patient Load (with
non-sliding digital image
receptor):
Maximum Patient Load (with
sliding digital image receptor): 550 lbs. (249.5 kg)
IMAGE RECEPTOR SPECIFICATIONS
Compatible With:
Receptor Longitudinal Travel: 20.0 inches (508.0 mm) **(see note 2)
**Note 2: 17.00 inches (431.8 mm) of receptor travel with QT-DDS option
Chapter 1 Specifications
85.0 inches (2159.0 mm)
35.5 inches (901.7 mm)
32.5 inches (825.5 mm)
32.5 inches (825.5 mm) *(see note 1)
21.0 inches (533.4 mm)
32 inches (812.8 mm)
10 inches (254 mm)
Fiber-resin (phenolic)
1.0 mm Aluminum
approx. 2.75 inches (69.9 mm)
48.0 inches (1219.2 mm)
26.0 inches (660.4 mm)
650 lbs. (295 kg)
600 lbs. (272.2 kg)
Grid Cabinet, Bucky, ACL Bucky
Revision Q
1
3
-
