SPECIFICATION

Model
CAPACITY VA/W
NOMINAL BATTERY VOLTAGE
LINE MODE
INPUT Nominal Voltage
Voltage Range
Normal Frequency
OUTPUT Voltage
Frequency
Output Waveform
EFFICIENCY
TRANSFER TIME
BATTERY MODE
OUTPUT Voltage
Frequency
Output Waveform
EFFICIENCY
OVERLOAD PROTECTION
PROTECTION
BATTERY CHARGER(powered by AC)
CHARGING ALGORITHM
AC CHARGE CURRENT
FLOATING CHARGING VOLTAGE
OVER CHARGING VOLTAGE
MPPT SOLAR CHARGER
Solar power to support load
CHARGING CURRENT
NOMINAL BATTERY VOLTAGE
MPPT operating voltage range
Max. PV Array Open Circuit Voltage
MAX. PV INPUT CURRENT
PWM SOLAR CHARGER
Solar power to support load
CHARGING CURRENT
NOMINAL BATTERY VOLTAGE
PWM operating voltage range
Max. PV Array Open Circuit Voltage
MAX. PV INPUT CURRENT
Physical
Total # of INVERTER Receptacles
Maximum Dimensions
Weight
Warning Diagnostics
Indicators
Audible Alarms
Environmental
Operating Temperature
Operating Relative Humidity
Management
Auto-Charger
Auto-Restart
3K
3000VA/2400W
24Vdc
220/230/240Vac
Wide mode: 90VAC-280VAC(default)
Narrow mode: 170VAC-280VAC
50/60Hz
220/230/240Vac
Follow the Utility
Follow the Utility
>96%(full R load, battery full charged)
Wide mode: 40ms max, Narrow mode: 8ms max
220/230/240Vac
50/60Hz(Auto detection)
Pure sine-wave
>80%
1min@ >110%,0s@>120%
Discharge, over-charged, over-load, short-circuit protection
3-stage charging
10/20/30/40A (selectable)
27V
32V
1600W
60A Max.
24V
30~80V
80V
50A
1350W
60A Max.
24V
30-36V
60V
60A
(1) Terminal Block
378mm(W)*263mm(H) *140mm(D)
30kg
INVERTER Status Display,
Low Battery, Overload, Fault
0C to 50C
0 to 90% NON-CONDENSING
Yes
Yes
17
5K
5000VA/4000W
48Vdc
54V
64V
3200W
48V
60~150V
150V
2700W
48V
60-72V
90V
30.3kg
