PROLiNK IPS Series User Manual page 10

Icon
Input source information
Configuration Program and Fault Information
Other Information
Battery Level
Load level
LCD Setting
When the power switch is turned on, pressing and holding "ENTER" button immediately for 3 seconds, the unit will into
the setting mode. Press "UP" or "DOWN" button to select setting programs. And then, press "ENTER" button to
confirm the selection or "ESC" button to exit. The unit will exit setting mode if no operating for 30s.
Function
Indicates utility power
Indicates the PV power
Indicates the setting programs
Indicates the warning and fault codes
Indicates mute
Indicates standby mode
Indicates power on mode
Indicates input, output, PV and battery information
Indicates battery level in battery mode and charging status.
Indicates the load level.
