Carefully unpack box.
1
START HERE
What's what?
All the important
internal components
labeled for you
9-V Battery
Must be installed before use.
Back of front panel shown with 9-V battery installed
Internal wiring not shown for clarity.
Q U IC K S TA R T
Make sure all components are present.
2
Keypad Unit
Nightlight/Status LEDs
Illuminate keypad and give helpful feedback
Reset Button
For performing reset procedures
on keypad
Keypad Unit
G UI DE
Transceiver Unit
9-V Battery
Key
Connection Terminals
For wiring to compatible
AC/DC power source and
gate operator or door opener
Relay Status LED
Indicates whether relay is
active or inactive
(Relay is active when lit)
Transceiver
Shown with cover removed.
Internal wiring not shown for clarity.
S-14-500
Model
Carriage Bolt
Hex Nut
Hole Plug
( x4 )
( x4 )
Power LED
Indicates whether or not unit has power
Programming Button
For pairing transceiver to keypad
Programming LED
Indicates status of pairing process
1 of 4
