- Page 1 UROCAP ™ LIGHT Service Manual LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
- Page 2 TRADEMARKS Urocap is a trademark of LABORIE Medical Technologies Canada ULC. Bluetooth is a registered trademark of Bluetooth SIG. Android is a trademark of Google Inc. Wi-Fi is a registered trademark of the Wi-Fi Alliance. MOTOROLA and product images are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. ASUS and product images are trademarks or registered trademarks of ASUSTeK Computer Inc.
-
Page 3: Table Of Contents
Treating And Disposing Of Product After Use ............... 9 Environmental Consideration Of Waste Disposal ............10 Help ........................10 Electromagnetic Compatibility (EMC) ................. 19 Symbols ......................26 End-User Software License Agreement .............. 27 LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 4: Tables
IEC 60601-1-2:2007 Table 1 Requirements ............22 IEC 60601-1-2:2007 Table 2 Requirements ............23 IEC 60601-1-2:2007 Table 4 Requirements ............24 IEC 60601-1-2:2007 Table 6 Requirements ............25 Labeling Symbols ....................26 LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 5: Introduction
Uroflow transducer. The information located in this manual is intended for the biomedical departments of hospitals or clinics. SPECIFICATIONS AND SYSTEM INFORMATION Upon request, LABORIE will make available any circuit diagrams, component part lists, and other technical documentation directly related to the Urocap IV Light system. - Page 6 Height with funnel: 440 - 795 mm (17.3 - 31.3”) Fixed Stand (MSM1075) Size: 395 mm (15.6”) L X 520 mm (20.5”) W Height with funnel: 420 - 775 mm (16.5 - 30.5”) LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
-
Page 7: Classifications
• Protects equipment from the harmful effects of water splashing from any direction (signified by the rating code 4). NOTE: If applicable to your uroflowmeter model, the IP rating will be visible on the device label. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 8: Applicable Directives And Standards
• EN ISO 15223-1 • EN 61000-3-2 • EN 1041 • EN 61000-3-3 • EN ISO 14155 Please refer to the EC Declaration of Conformity for a list of additional product related standards. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 9: Equipment Setup
5 meters (17 feet); the maximum distance between the mobile device and an electrical outlet is 3 meters (10 feet); and the maximum distance between the wireless printer and an electrical outlet is 2 meters (6 feet). LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 10: Calibration
2. Tap Device Options then tap Calibration . 3. Tap the calibration option icon (weight or water) to start calibration. Follow the on-screen instructions to complete the calibration. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 11: Cleaning And Maintenance
• The Urocap IV should be cleaned using a damp cloth with alcohol, soap, or disinfectant detergent. Figure 2 : Cleaning the Urocap IV • The unit should be stored in a cool and dry area at room temperature. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 12: Battery: Charging And Preventive Maintenance
• Lift the tab on the bottom of the Urocap IV to reveal the charging port ( A ). • Plug one end of the charging power supply cord into the charger port on the bottom of the device and the other end into an electrical outlet. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 13: Preventive Maintenance
LABORIE. TREATING AND DISPOSING OF PRODUCT AFTER USE • After use, discard any packaging according to your institution’s standard operating procedures on medical waste handling. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 14: Environmental Consideration Of Waste Disposal
— especially the drinking water system. Normally, this is not an issue in areas that have proper sewage systems with water treatment procedures. In this case, the most convenient way is to use these sewage systems. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 15: Help
HELP If problems continue, contact LABORIE’s Service team at 1-800-333-1039 or E- mail: service@laborie.com . Table 2: Troubleshooting - Mobile Device YMPTOM OSSIBLE AUSE HECK ORRECTIVE CTION Mobile Device does Is the WIFI on the Ensure the Mobile Device is only connected to... - Page 16 2. Scroll through the device is turned apps and select the Settings icon. Home 3. Select the menu item. Urocap IV Light (UDS 4. Select the Light) application. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
- Page 17 AUSE HECK ORRECTIVE CTION 5. Click the Home button on the mobile device to set the Urocap IV Light (UDS Light) application as the Home application. The Urocap IV Light (UDS Light) Home screen will now appear. For any additional problems not mentioned here, please refer to the owner’s manual for your mobile device.
-
Page 18: Troubleshooting - Bluetooth Connections
HP wireless direct can be used while the printer is also connected to a computer using USB cable or to a network using a wireless connection. Accidentally Tap the Reprint Last Test icon. tapped outside of the printing window? LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... - Page 19 For any additional problems not mentioned here, please refer to the owner’s manual for the printer. Note: The Laborie Urocap IV has a medical grade power supply available for the laptop, but the desktop printer is not medically isolated and must not be used within the patient environment or directly connected to the laptop if the laptop is within the patient environment.
- Page 20 Devices not Connect/add the devices to the system. See connected in owner’s manual for more information. app? LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
- Page 21 Funnel is touching Adjust commode chair or Urocap IV. beaker? Incorrect beaker Use beakers supplied by LABORIE ONLY. in use? Does the Calibrate the Urocap IV and start over. Uroflowmeter require calibration? LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
-
Page 22: Troubleshooting - User Notification Messages
Urocap IV and change to disconnected mode. the Mobile Device? Is the Urocap IV and/or 3. Tap the icon again. Wait 60 seconds for Mobile Device re-connection to occur. out of range? LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... - Page 23 1. Plug in the Urocap IV charger and tap the Shutdown? insufficient Urocap IV icon in the software. The icon battery will change to disconnected mode. power? 2. Tap the icon again. Wait 60 seconds for re-connection to occur. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
-
Page 24: Electromagnetic Compatibility (Emc)
Magnetic Field Immunity Test. IEC 61000-4-11:2004 Testing and Measurement Techniques - Voltage Dips, Short Interruptions and Voltage Variations Immunity Tests. ISO 17025:2005 General requirements for the competence of testing and calibration laboratories. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... - Page 25 • Connect the non-medical system equipment into an outlet on a circuit different from that to which the Urocap IV Light system is connected. • Consult the dealer or experienced technical personnel for help. Changes or modifications not expressly approved by LABORIE could void the user’s authority to...
- Page 26 • The use of accessories, transducers, and cables other than those specified by LABORIE may result in increased EMISSIONS or decreased IMMUNITY of the.Urocap IV Light. • The Urocap IV Light needs special precautions regarding EMC and needs to be installed and put into service according to the EMC information provided in this EMC section.
-
Page 27: Iec 60601-1-2:2007 Table 1 Requirements
It may be necessary to take mitigation measures, such as re- orienting or relocating the ME EQUIPMENT shielding the location. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 28: Iec 60601-1-2:2007 Table 2 Requirements
Power Power frequency magnetic fields should Frequency be at levels characteristic of a typical Magnetic Field location in a typical commercial or 3 A/m 3 A/m (50/60 Hz) hospital environment. IEC 61000-4-8 LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 29: Iec 60601-1-2:2007 Table 4 Requirements
If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the equipment. b) Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m. LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 30: Iec 60601-1-2:2007 Table 6 Requirements
3, 5 �� = [ ] √�� �� = [ ] √�� �� = [ ] √�� ��1 ��1 ��1 0.01 0.12 0.12 0.24 0.37 0.37 0.74 1.17 1.17 2.34 3.69 3.69 7.38 LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 31: Symbols
Representative in the Manual European Community Not for general waste. Dispose of in Serial Number accordance to local regulations. Date Of Manufacture Manufacturer IP54 Radio Equipment Alert IP Rating Do Not Immerse LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... -
Page 32: End-User Software License Agreement
END-USER SOFTWARE LICENSE AGREEMENT Find licenses and terms for LABORIE products and services in the following locations: End User License Agreement: http://www.laborie.com/eula/ Terms and Conditions: http://www.laborie.com/terms-and-conditions/ LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00... - Page 33 LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
- Page 34 LABORIE Urocap IV Light Service Manual UCL-SM01 V7.00...
