- Page 1 ADJUSTABLE TRESTLE MODEL NO: CTA150 PART NO: 6600018 ASSEMBLY INSTRUCTIONS LS0518 - ISS 2 ORIGINAL INSTRUCTIONS...
- Page 2 INTRODUCTION Thank you for selecting this Clarke Adjustable Trestle. Read this manual before use. The safety precautions in this manual will help you use the trestle safely. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase.
- Page 3 SPECIFICATIONS Dimensions L x W x H 685 x 590 x 815-1310 mm Maximum Load 150 kg WHAT IS SUPPLIED Number Description Part number Legs (pair) Lower Cross Brace Upper Cross Brace Pivot Plate Fixings Pack Support Bar Support Frame Upright Parts &...
- Page 4 ASSEMBLY MAIN FRAME 1. Join both sets of legs together with the upper cross brace. 2. Secure the upper cross brace. • The small machine screw. washer, spring washer and nut must be installed towards the front of the stand. •...
- Page 5 SUPPORT FRAME 1. Fit the 2 support frame uprights to the support bar as shown. 2. Join them together using 1 bolt, 2 washers and a nut in each hole (4 holes in total). 3. Slide the support frame into the main frame as shown.
- Page 6 OPENING/CLOSING THE WORKBENCH OPENING 1. Spread the front and rear legs. 2. Press down on the lower locking bar (1) as shown. 3. Slide the locking latch over the lug (2). 4. Test the stability of the stand by rocking it before use. SETTING THE SUPPORT HEIGHT 1.
- Page 7 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
