- Page 1 ENGINE STAND MODEL NO: CES450 PART NO: 7610121 USER INSTRUCTIONS GC1215...
- Page 2 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
- Page 3 4. Do not use the stand if it is damaged. 5. Use the stand in a suitable, well lit work area. 6. Keep the work area clean and tidy and free from unrelated items. 7. Do not use the stand when you are tired or under the influence of alcohol, drugs or intoxicating medication.
- Page 4 1 x Fixings kit including nuts, bolts, washers and locating pin. Visually inspect all components to ensure that no damage was suffered in transit. Any deficiencies should be reported to your CLARKE dealer immediately. TOOLS REQUIRED Open/combination wrench (12, 17, 19 & 29 mm) or an adjustable wrench.
- Page 5 ASSEMBLY IMPORTANT: Due to the weight of the components, we recommend that you get assistance during assembly. Refer to the parts diagram on page 7 for parts identification. 1. Loosely bolt the upright column to the rear cross member. 2. Insert the centre spine to the rear cross member and loosely bolt together from underneath.
- Page 6 MOUNTING THE ENGINE TO THE STAND 1. The mounting plate has four adjustable arms with long bolt holes. This is where the engine will mount to the engine stand, using suitable bolts which are compatible with threaded holes in the engine block. 2.
- Page 7 PARTS DIAGRAM PART NO DESCRIPTION PART NO DESCRIPTION Main Column Flat Washer 3/8” Rear Crossmember Wheel Bolt (1/2” x 3”) Hex Nut 3/8” Mounting Plate Flat Washer 3/4” Locking Pin Locking Clip Adhesive Label Centre Spine Mounting Arm Short Crossmember Bolt 1/2”...
