Summary of Contents for Clarke Strong-Arm CES340
- Page 1 ENGINE STAND MODEL NO: CES340 PART NO: 7610124 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1018 Issue 3...
-
Page 2: Technical Specifications
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Safety Precautions
3. Ensure that the stand is in good working order. Have any damaged parts repaired or replaced immediately. Use genuine Clarke parts only. The use of unauthorised parts may be dangerous and invalidate the guarantee. - Page 4 2 x Rear wheels pin. Visually inspect all components to ensure that no damage was suffered in transit. Any deficiencies should be reported to your CLARKE dealer immediately. TOOLS REQUIRED • Open or ratchet ring spanner (19 mm) or an adjustable wrench.
- Page 5 ASSEMBLY IMPORTANT: Due to the weight of the components, we recommend that you get assistance during assembly. 1. Slide the front leg into the socket at the base of the main support column and sit together on the rear cross member. Use the 70mm bolt, washers &...
-
Page 6: Maintenance
4. Remove the locating pin, then remove the mounting plate assembly from the engine stand. 5. Using compatible bolts, pass them through the mounting arms and bolt them to the engine where the transmission was mounted to the block. Mount two arms low down on the engine and bolt the other two as high as possible. -
Page 7: Parts Diagram
PARTS DIAGRAM PART NO DESCRIPTION PART NO DESCRIPTION Column Bolt (M14 x 60) Front Leg Spring Washer M14 Cross-member Flat Washer Bolt (M10 x 70) Hex Nut Washer flat M10 Castor with brake Hex Nut (M10) Rear Wheel Spring Washer M10 Flat Washer Engine Mounting Plate Spring Pin...
