- Page 1 ASSEMBLY INSTRUCTIONS Description : TUSCAN KITCHEN ISLAND Item No. : WC-10 ITEM NO : WC-10 Printed in Vietnam ISSUED JUN 30, 2015 THIS ITEM IS PACKED IN TWO CARTONS - 1 -...
- Page 2 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Bottom panel ITEM NO : WC-10 Printed in Vietnam ISSUED JUN 30, 2015 THIS ITEM IS PACKED IN TWO CARTONS - 2 -...
- Page 3 ( 6.5 x 19mm) (M4 x 28 mm) Allen key Knob (M4x80mm) NOTE: HARDWARE IS PACKED IN CARTON WC-10B ITEM NO : WC-10 Printed in Vietnam ISSUED JUN 30, 2015 THIS ITEM IS PACKED IN TWO CARTONS - 3 -...
- Page 4 STEP 2 Attach bottom panel (B) to the legs (C) with bolts (1) and washers (2) and (3) as shown below. Tighten with Allen key (6). ITEM NO : WC-10 Printed in Vietnam ISSUED JUN 30, 2015 THIS ITEM IS PACKED IN TWO CARTONS...
- Page 5 STEP 3 Attach knob (5) to front of drawer with pan head screw (4). Tighten with the screwdriver. ITEM NO : WC-10 Printed in Vietnam ISSUED JUN 30, 2015 THIS ITEM IS PACKED IN TWO CARTONS - 5 -...
