Desperado 17.5 inch Grill
MODEL# CG2065303-RG
OWNER'S MANUAL
ASSEMBLY AND OPERATING INSTRUCTIONS
Tools required for assembly: (Not Included) Pliers, Philips Screwdrivers,
Adjustable Wrench.
Keep this manual for future reference.
WARNING
OUTDOOR USE ONLY.
Never use grill indoors. Carbon Monoxide poisoning that can lead to death.
CG2065303-RG - ENGLISH
P.1
20170615 V 1
Advertisement
Table of Contents
Related Manuals for RiverGrille Desperado CG2065303-RG
Summary of Contents for RiverGrille Desperado CG2065303-RG
- Page 1 Desperado 17.5 inch Grill MODEL# CG2065303-RG OWNER’S MANUAL ASSEMBLY AND OPERATING INSTRUCTIONS Tools required for assembly: (Not Included) Pliers, Philips Screwdrivers, Adjustable Wrench. Keep this manual for future reference. WARNING OUTDOOR USE ONLY. Never use grill indoors. Carbon Monoxide poisoning that can lead to death. CG2065303-RG - ENGLISH 20170615 V 1...
- Page 2 WARNING Only use this grill on a hard, level, non-combustible, stable surface (concrete, ground, etc.) capable of supporting the weight of the grill. Never use on wooden or other surfaces that could burn. When the grill is in use, maintain a clearance of at least 36” (1 m) between the hot grill and any combustible materials, such as bushes, trees, wooden decks, wooden fences, buildings, etc.
- Page 3 WARNING When grilling, grease from meat may drip into the charcoal and cause a grease fire. If this should happen, close the lid to suffocate the flame. Do not use water to extinguish grease fires. Use caution when opening the lid. Keep hands, face and body a safe distance away. Flash flare ups may occur when air comes into contact with fire or hot coals.
- Page 4 ASSEMBLY INSTRUCTIONS THANK YOU FOR PURCHASING THIS DESPERADO SMOKER Read all safety warnings & assembly instructions carefully before assembling or operating your grill. 1-888-837-1380 For assembly assistance, missing or damaged parts, please call Rankam customer service at (U.S. only) , Monday thru Friday 8AM to 5PM Pacific Standard Time or email to customerservice@rankam.com (Proof of purchase will be required.) Inspect contents of the box to ensure all parts are included and undamaged.
- Page 5 Components 1. Chimney Cover 2. Handle 3. Axle 4. Grill body 1 pc 2 pcs 1 pc 1 pc 5. Cooking grates 6. Ash Pan 7. Air Vent 8. Chimney 2 pcs 1 pc 1 pc 1 pc 9. Side Table 10.
- Page 6 Hardware List Item Item name Diagram Bolt M6 x 40 Bolt M6 x 12 Flange Nut M6 Spring “R” Pin M8 Cup Nut Assembly Procedures Symbol: The following symbols will be shown in each procedure for indication of tightening the bolt and nut if necessary. Hand Tighten only at this time Tighten with tools at this time Some steps may require the assistance of a friend.
- Page 7 Step 1. Step 2. CG2065303-RG - ENGLISH 20170615 V 1...
- Page 8 Step 3. Step 4. CG2065303-RG - ENGLISH 20170615 V 1...
- Page 9 Step 5. Step 6. CG2065303-RG - ENGLISH 20170615 V 1...
- Page 10 Step 7. Step 8. CG2065303-RG - ENGLISH P.10 20170615 V 1...
- Page 11 Step 9. Step 10. Tighten all hardware CG2065303-RG - ENGLISH P.11 20170615 V 1...
- Page 12 WARNING DO NOT use grill without charcoal ash pans in place. DO NOT attempt to remove charcoal ash pans while pan contains hot coals. WARNING Place the grill outdoors on a hard, level, non-combustible surface away from roof overhang or any combustible material.
- Page 13 Instruction for reference only: Begin with three full sheets of newspaper. Take 2 sheets of newspaper and roll each into a tube shape and then give them a little twist to form each of them into a straight rope like shape. Be careful to not twist too tight. Turn the charcoal chimney starter over and place both pieces of rolled and twisted newspaper along the inside bottom of the charcoal chimney starter to form a complete circle.
- Page 14 If using a Charcoal Chimney Starter, follow all manufacturer’s warnings and instructions regarding the use of their product. Start with 2.2 lbs (1.0 kg) of charcoal. When charcoal is burning strong, carefully place hot coals in centre of each charcoal grate. Instruction for reference only: Begin with three full sheets of newspaper.
-
Page 15: Regulating Heat
Flavouring Wood To obtain your favorite smoke flavour, experiment by using chunks, sticks or chips of flavour-producing wood such as hickory, pecan, apple, cherry, or mesquite. Most fruit or nut tree wood may be used for smoke flavouring. Do not use resinous wood such as pine as it will produce an unpleasant taste. -
Page 16: After-Use Safety
AFTER-USE SAFETY WARNING Always allow grill and all components to cool completely before handling. Never leave coals and ashes in grill unattended. Make sure coals and ashes are completely extinguished before removing. Before grill can be left unattended, remaining coals and ashes must be removed from grill. Use caution to protect yourself and property. -
Page 17: Limited Warranty
LIMITED WARRANTY 1. Manufacturer warrants this Product to be free from defects in workmanship and materials for a period of Ninety (90) days from the date of purchase, PROVIDED claims are submitted, in writing, with proof of purchase. 2. If any part of this item fails because of a manufacturing defect within the Limited Warranty Period, Manufacturer offers to replace such part(s) provide that such parts have not been improperly repaired, altered, or tampered with or subject to misuse, abuse or exposed to corrosive conditions. -
Page 18: Obtaining Replacement Parts
Should you encounter any problem Obtaining replacement parts CALL US FIRST. Do not return product to the store. WE CAN HELP. Rankam (China) Manufacturing Co. Ltd. 18/F., New Lee Wah Centre, 88 Tokwawan Road, Kowloon, Hong Kong customerservice@rankam.com Please contact Rankam Customer Service at or at 1-888-837-1380, Mon to Fri, 8:00 a.m.
