Nidek Medical LE-9000LX Operator's Manual

Nidek Medical LE-9000LX Operator's Manual

Patternless edger
Hide thumbs
Table of Contents

Advertisement

Quick Links

PATTERNLESS EDGER
LE-9000LX
Model
OPERATOR'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE-9000LX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nidek Medical LE-9000LX

Summary of Contents for Nidek Medical LE-9000LX

  • Page 1 PATTERNLESS EDGER LE-9000LX Model OPERATOR’S MANUAL...
  • Page 2 NIDEK CO., LTD. : 34-14, Maehama, Hiroishi-cho, Gamagori, Aichi 443-0038, Japan (Manufacturer) Telephone: (81-533) 67-6611 Facsimile: (81-533) 67-6610 NIDEK CO., LTD : 3F Sumitomo Fudosan Hongo Bldg., 3-22-5, Hongo, (Tokyo Office) Bunkyo-Ku, Tokyo 113-0033, Japan Telephone: (81-3) 5844-2641 Facsimile: (81-3) 5844-2642 NIDEK INCORPORATED : 47651 Westinghouse Drive, Fremont, California 94539, U.
  • Page 3 BEFORE USE OR MAINTENANCE, READ THIS MANUAL. This Operator’s Manual contains information necessary for the operation of the NIDEK PATTERNLESS EDGER Model LE-9000LX Type PC, Type PL4, Type PLB, and Type PLB-2R. This manual provides operating procedures, cautions for safety, specifications, accessories, and maintenance.

  • Page 4: Table Of Contents

    Table of Contents § 1 Page INTRODUCTION ......................1-1 1.1 Outline of the Product ....................1-1 1.2 Symbol Information ....................1-2 § 2 SAFETY ........................2-1 2.1 Cautions during Use ....................2-1 2.2 Storage ........................2-3 2.3 Transport ........................2-3 2.4 Installation ........................
  • Page 5 Page 4.5.1.1 Blocking progressive power lens ............4-18 4.5.2 Blocking in passive mode ................4-19 4.5.3 Blocking bifocal lens ..................4-20 4.6 Processings ......................4-21 4.6.1 Beveling ......................4-21 4.6.1.1 Auto processing mode ................. 4-22 4.6.1.2 Guided processing mode ..............4-25 4.6.1.3 Guided processing mode (Tilting function) ..........
  • Page 6 § 8 Page MAINTENANCE ......................8-1 8.1 Wheel Dressing ......................8-1 8.2 Replacing the Water and Filter (115 V regions) ............8-4 8.2.1 Replacing the water (when the optional FP-100 is equipped) ......8-4 8.2.2 Replacing the water (when the optional FP-100 is not equipped) ......8-7 8.3 Replacing the Water and Filter (230 V regions) ............

  • Page 7: Introduction

    INTRODUCTION § 1 1.1 Outline of the Product This instrument is a fully-automatic lens edger which reads the lens outline of eyeglasses directly from frames and processes a lens into the shape of frames. This edger has a processing unit at the center front, a control panel for the processing unit at the front, a display panel at the right front, a tracing unit, and a control panel for the tracing unit at the upper side.

  • Page 8: Symbol Information

    1 - 2 1.2 Symbol Information This symbol on the body indicates that caution should be taken. It is necessary to refer to Operator’s Manual before using the instrument. This symbol means caution for electric shock. The inside of the instrument includes high- voltage circuit.

  • Page 9: Safety

    SAFETY § 2 In this manual, Signal Words are used to designate a degree or level of safety alerting, whose definitions are as follows. Indicates a potentially hazardous situation which, if not avoided, WARNING: could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or property damage accident.
  • Page 10 2 - 2 CAUTION • Never disassemble nor touch the internal structure. Electric shock or failure of the instrument may occur. • Never yank the power cord to disconnect it from the wall outlet. Always hold the plug. This can damage the metal core of the cord and may result in fire, short circuit or electric shock.

  • Page 11: Storage

    2 - 3 CAUTION • When removing the lens cup with the cup remover, hold the lens through the soft cloth. If you hold the lens with bare hands, the lens edge may hurt your hands. • Be sure to confirm that wash water (for the inside wall of the processing chamber) and cooling water (for the wheels) flow properly.

  • Page 12: Installation

    2 - 4 2.4 Installation CAUTION • Use the instrument under the following conditions. - A dust free environment - A stable place with no tilt - A vibration and shock free environment • Install the instrument where it can be used at the following temperature and humidity. Use conditions Temperature: 5 - 40ºC...

  • Page 13: Wiring

    2 - 5 2.5 Wiring CAUTION • Do not overload one electrical outlet. Abnormal heat generation may occur at the outlet in conjunction with the other devices. • Be sure to use the socket which meets the power specifications. If the line voltage is too high or low, the instrument may not perform properly. Malfunction or fire also may occur.
  • Page 14 2 - 6 CAUTION • Be sure to use the specified fuses for replacement. If not, fire may occur. • Be sure to use the suitable dressing stick for wheel dressing. If not, the wheel may be damaged and normal processing cannot be performed. •...

  • Page 15: Disposal

    2 - 7 CAUTION • Be sure to use the specified stocking filter only. If not, the filter or water supply pipe may become clogged. • The stocking filter is disposable. Do not reuse it. A filter which has a rip or run in it does not function as a filter, and therefore, the water supply pipe may become clogged.

  • Page 16: Labels

    2 - 8 2.9 Labels The following labels provide safety information about each part. <Front view> <Rear view> (115 V regions only)
  • Page 17 2 - 9 <Top view>...

  • Page 18: Safety Function

    2 - 10 2.10 Safety Function For safety use, various functions are provided. [Soundproof cover check function at processing start] Lens processing does not start unless the soundproof cover is closed. CAUTION • If the soundproof cover is opened during processing, the instrument does not stop. Be sure not to open the soundproof cover during processing since it is hazardous.
  • Page 19 2 - 11...

  • Page 20: Configuration

    CONFIGURATION § 3 [Whole system] Tracing unit cover Control panel Soundproof cover for tracing unit Display panel Control panel for processing unit Drawer Table [Rear side of the main body] Power switch Cooling fan Contrast control Inlet RS-232C interface connector Connector for barcode scanner Outlet for pump 1 Outlet for pump 2...
  • Page 21 3 - 2 Soundproof cover Contrast control Prevents water and processing wastes from Adjusts the contrast of the display panel. splashing, and it blocks processing sound. Turn the control according to its use envi- The processing unit is contained under this ronment to clear the screen.
  • Page 22 3 - 3 [Processing unit] Feelers Chamber-cleaning nozzle Adapter Lens clamp Feedwater nozzle Wheels...
  • Page 23 3 - 4 Chamber-cleaning nozzle Wheels During the lens edging, the water supplied Several different types of wheels compose by the nozzle washes processing wastes a set of processing wheels. away before they scatter within the process- a. Roughing wheel for plastic lens: ing chamber.
  • Page 24 3 - 5 [Tracing unit] Rim clips Pattern tracing pin Upper slider Lower slider Stylus Rim clips Pattern setting unit support [Control panel for tracing unit]...
  • Page 25 3 - 6 Lower slider Starts a single-tracing of the left rim. Upper slider Frames are set between these sliders. Rim clips Starts both-tracing of the right and left rims. The rims of frames are held by these clips. Each upper and lower slider has two clips.
  • Page 26 3 - 7 [Control panel for processing unit] Selects a lens material; PLA (plastic), HPL (high index plastic), PC (polycarbonate), Selects processing conditions. GLS (glass), ACR (acrylic resin), or TRX (trivex). (With Type PLB, GLS cannot be Processing mode selected.) setting setting MTL/CEL (ZYL)
  • Page 27 3 - 8 Turns ON/OFF the polishing mode. (This Stops processing. key does not function with Type PC.) Starts processing. Turns ON/OFF the frame changing mode. Fixes a lens with the lens clamp or release Specifies the side of a lens to be edged, a lens from the clamp.
  • Page 28 3 - 9 [Display Panel] • LAYOUT DISPLAY Lens layout and prescription data input, etc. are performed on this display. Minimum lens diameter Frame pupillary distance Pupillary distance Height of optical center Size compensation value Layout mode Traced outline Memory address Frame material Polishing indication Lens material...
  • Page 29 3 - 10 Size compensation value (SIZ) R/L indication Indicates the compensation value for the Indicates the selected side of a lens to be desired finished size in diameter, based on edged [R/L]. the traced size of frame or pattern (0.00). [–9.95 - + 9.95 mm (step: 0.05 mm)] Traced outline Represents the plain figure of a traced out-...
  • Page 30 3 - 11 • Bevel simulation display This display is shown while a bevel is simulated (when the tilting function is Edge thickest point Sectional view position line OFF). Bevel sectional view Bevel curve Bevel tip point Frame curve Edge thinnest point Tilt base position This display is shown while a bevel is simulated (with the tilting function).
  • Page 31 3 - 12 Frame curve (F CRV) Tilt base position This is the base bevel position for deter- Indicates the frame curve value measured by the tracing unit. mining a tilting amount. Bevel tip point (PNT) Indicates the amount by which the bevel is moved, either backward or forward.
  • Page 32 3 - 13 • MENU display This display serves the selections such as Process counter, Wheel dressing, Size ad- justment, and Bevel adjustment. This is used to perform maintenance or adjust- ment of the edger. • Parameter exchange mode display This is a display to set parameters.

  • Page 33: Operating Procedures

    OPERATING PROCEDURES § 4 4.1 Operation Flow Power-on 4.3 Tracings 4.3.1 Tracing frames (p. 4-4) 4.3.1.1 Tracing both rims (p. 4-4) 4.3.1.2 Tracing single rims (p. 4-5) 4.3.1.3 Semiauto tracing (p. 4-5) 4.3.1.4 Tracing goggle type frames (p. 4-6) 4.3.2 Tracing patterns (p. 4-7) 4.3.3 Tracing dummy lenses (p.
  • Page 34 4 - 2 4.6 Processings 4.6.1 Beveling (p. 4-21) 4.6.1.1 Auto processing mode (p. 4-22) 4.6.1.2 Guided processing mode (p. 4-25) 4.6.1.3 Guided processing mode (tilting function) (p. 4-29) 4.6.1.4 EX lens processing mode (p. 4-32) 4.6.2 Flat (rimless) edging (p. 4-36) 4.6.2.1 Flat (rimless) edging mode (p.

  • Page 35: Preparation

    4 - 3 4.2 Preparation 1. Plug the power cord in the wall outlet. CAUTION • Do not put many loads on one electrical outlet. It may cause fire. • Pins of the plug must be fully inserted into the socket. Incomplete connection may cause fire.

  • Page 36: Tracings

    4 - 4 4.3 Tracings 4.3.1 Tracing frames NOTE • Perform the dummy lens tracing for rims which possess low stiffness such as thin-rim frames. If the rim has low stiffness, distortion may occur and correct measurment cannot be obtained. 4.3.1.1 Tracing both rims This is a procedure to measure the outline of both rims as well as the FPD (Frame Pupillary Distance).

  • Page 37: Tracing Single Rim

    4 - 5 NOTE • If there is 1 mm or more of difference in circumference between right and left rims, the tracing error occurs (Retracing starts automatically and the LEDs beside blink for a few seconds) and pressing does not read the traced data. In such a case, perform the single rim tracing.

  • Page 38: Tracing Goggle Type Frames

    4 - 6 4. Start tracing. Press When tracing is complete for one rim, the stylus will move to the other rim and stop at the tracing start position. 5. Trace the other rim in the same manner as Steps 3 and 4. 4.3.1.4 Tracing goggle type frames When sharply warped frames such as goggles are traced, the stylus may come off the bevel groove.

  • Page 39: Tracing Pattern

    4 - 7 4.3.2 Tracing patterns White button 1. Set a pattern onto the pattern setting unit. 1) Set a pattern while pressing the white button on the pattern setting unit. Make sure that the pattern is pushed as far as it will go.

  • Page 40: Tracing Dummy Lens

    4 - 8 3. Press either For tracing the right pattern Press For tracing the left pattern Press The tracing pin comes out and then tracing starts. 4. When tracing is completed, remove the pattern setting unit. When tracing is complete, the tracing pin will be automatically stored.
  • Page 41 4 - 9 Lens cup 2) Affix the provided double-coated adhesive tape on a lens cup. 3) Block the convex side of the dummy lens with the lens cup, using a centering device. Align the marks on the dummy lens to the direction of the groove on the lens cup to block it.

  • Page 42: Tracing During Processing

    4 - 10 4.3.4 Tracing during processing It is possible to perform the next tracing during processing. Set frames and press After the processing is complete, press . The data of the traced outline will be set and shown on the display. 4.3.5 Stopping tracing To stop tracing, follow the instructions below.

  • Page 43: Layouts

    4 - 11 4.4 Layouts 4.4.1 Selecting processing conditions and inputting layout data 1. Select processing conditions. 1) Specify the material of a lens with [PLA (plastic), HPL (high index plastic), PC (polycarbonate), GLS (glass), ACR (acrylic resin), or TRX (trivex)] CAUTION •...
  • Page 44 4 - 12 NOTE • EX lenses cannot be processed in auto processing mode and guided processing mode. Process an EX lens after checking the bevel position or groove position in EX lens procesing mode. • Cataract lenses cannot be processed in auto processing mode. Edge a cataract lens after setting the bevel curve to the rear surface and checking the bevel position or groove position in guided processing mode.
  • Page 45 4 - 13 2) Input the height of the optical center. Align the cursor to and input a height of the optical center from the level of the frame center with 3) To correct the finished lens size, align the cursor to and input the corrective value with e.g.

  • Page 46: Inputting Height From Lens Outline

    4 - 14 4.4.2 Inputting height from lens outline 1. Select an inputting form. Align the cursor to and select either of the followings with PD : Height of the optical center from the straight-down point on the lens out- line.

  • Page 47: Layout Of Bifocal Lens

    4 - 15 4.4.2.1 Layout of bifocal lens 1. Select processing conditions. See “4.4.1 Selecting processing conditions and inputting layout data” (p. 4-11). 2. Select (bifocal) for the layout mode. 3. Input the prescribed PD for the near vision (PD of segment) at 4.

  • Page 48: Layout Of Progressive Power Lens

    4 - 16 4.4.2.2 Layout of progressive power lens 1. Select processing conditions. See “4.4.1 Selecting processing conditions and inputting layout data” (p. 4-11). 2. Select (Active) for the layout mode. 3. Input the prescribed PD at 4. Input the height of the eye point marked on a dummy lens.

  • Page 49: Eye Point Layout

    4 - 17 4.4.3 Eye point layout This is a form to input the optical center by the distance from the nasal and bottom side of the lens outline. This form serves to specify the position of the eye point, which is marked on dummy lenses, as the optical center.

  • Page 50: Blocking Lenses

    4 - 18 4.5 Blocking Lenses A blocking position of the suction cup varies with the layout mode (Active mode, Bifocal mode, Passive mode). 4.5.1 Blocking in active mode 1. Mark at the optical center of a lens with a lensmeter.

  • Page 51: Blocking In Passive Mode

    4 - 19 4.5.2 Blocking in passive mode This is a procedure to block at the rim center by decentering the optical center. When PAS (Passive) is selected for the layout mode, how much and in what direction the optical center should be decentered appears at after lens layout is finished.

  • Page 52: Blocking Bifocal Lens

    4 - 20 4.5.3 Blocking bifocal lenses When BF (bifocal) is selected for the layout mode, a lens is blocked at the specified value UP and OUT position from the top line center of segment. Be sure to block the lens as instructed below since the edger processes the lens with the specified values.

  • Page 53: Processings

    4 - 21 4.6 Processings Processing mode is specified with See Step 1 of “4.4.1 Selecting processing conditions and inputting layout data” (p. 4-11). Processing mode setting setting Auto processing mode (see p. 4-22) MTL/CEL (ZYL) Beveling Guided processing mode (see p. 4-25) MTL/CEL (ZYL) EX lens processing mode (see p.

  • Page 54: Auto Processing Mode

    4 - 22 4.6.1.1 Auto processing mode In this mode, a computer-calculated bevel is produced on the lens edge. 1. Check the processing conditions. : MTL or CEL (ZYL) : AUT 2. Set a lens to the adapter in the processing unit.
  • Page 55 4 - 23 3. Close the soundproof cover. Processing does not start even if is pressed unless the soundproof cover is closed. WARNING • Be sure to keep the soundproof cover closed while processing a lens. If the soundproof cover is opened during processing, the instrument does not stop. Spray including processing waste may cause eye damage.
  • Page 56 4 - 24 NOTE • Be sure to move a glass lens within the roughing wheel for glass lenses. If the glass lens contacts the other wheels, it may damage the wheels or the glass lens may crack. • The adjusted contact position with the wheel is effective only during roughing of one lens.

  • Page 57: Guided Processing Mode

    4 - 25 4.6.1.2 Guided processing mode This is a mode to input the value of bevel curve and bevel position manually. 1. Check the processing conditions. : MTL or CEL (ZYL) : GUI 2. Set a lens to the adapter in the processing unit.
  • Page 58 4 - 26 6. Adjust the bevel position. (a) Changing the bevel position only at the part that the edge is thick B CRV 1) Align the cursor to 2) Change the bevel curve value to move the bevel position toward the front or rear surface of the lens.
  • Page 59 4 - 27 (b) Changing the position of the whole bevel parallel to itself 1) Press to simulate the bevel at the point that the edge is thinnest ( ). 2) Align the cursor to 3) Change the bevel tip point value to move the bevel position toward the front or rear surface of the lens.
  • Page 60 4 - 28 9. Start processing. Press Roughing Finishing Polishing (Only when is selected by Type PLB or PLB-2R.) Processings are complete. [The Layout display returns.] 10. Remove the lens. WARNING • Open the soundproof cover after making sure that the wheels have come to a complete stop. •...

  • Page 61: Guided Processing Mode (Tilting Function)

    4 - 29 4.6.1.3 Guided processing mode (Tilting function) The tilting function of bevel is available in the guided processing mode, in which the bevel curve can be specified manually. If the difference in width between the edge thickest point and thinnest point is extreme, the mounted lens does not look nice.
  • Page 62 4 - 30 B CRV 3) Align the cursor to with , and set the bevel curve value with Press once to delete A (Auto-curve), and then set the desired value. e.g.) A4.3: A bevel position is computer-calculated from the ratio. 4.3: A bevel position is calculated from the spheric curve of the lens.
  • Page 63 4 - 31 3. Restart processing. Press to restart processing. If the bevel is completely off the lens edge, the two short beeps will be produced. The sectional view position line automatically rotates along the whole traced outline and bevel section at each position will be shown.

  • Page 64: Ex Lens Processing Mode

    4 - 32 4.6.1.4 EX lens processing mode This mode serves to edge EX lenses. In this mode, the beveling which has the curve profiling the rear surface is performed. As for a cataract lens which has a large dilation on its front convex surface, edge a lens in the EX lens processing mode if the lens processing cannot be performed in guided processing mode (rear base curve) due to the lens shape measurement error.
  • Page 65 4 - 33 5. Simulate the bevel section at each point of the outline on the display. The sectional view position line rotates counterclockwise. The sectional view position line rotates clockwise. To stop the line movement, press again. : The sectional view position line jumps to the point that the lens edge is thinnest ( ) and thickest ( ) alternately.
  • Page 66 4 - 34 Concrete example of the tilting function The procedures of processing EX lenses with the tilting function are described. To use the tilting function, it is necessary to set the “TILT Function” parameter to “Exec”. See “5.2 Parameter Settings” (p. 5-2). EX lenses have the distance part on its upper half and the near part on its lower half as the figure, and the difference between the top edge width and the bottom one is wide.
  • Page 67 4 - 35 Inputting tilting amount The bevel position has been moved backward in Step though the upper part of the edge is thick. Move the bevel forward by inputting a minus value to “TILT”. In doing so, always observe the bevel on the boundary between the distance and near parts. In most cases, the edge thinnest point is on the boundary.

  • Page 68: Flat (Rimless) Edging

    4 - 36 4.6.2 Flat (rimless) edging The EX lens flat edging mode is also available for EX lenses in the normal flat edging. 4.6.2.1 Flat (rimless) edging mode 1. Check the processing conditions. : PNT* or NYL : (Blank) 2.
  • Page 69 4 - 37 5. Remove the lens. WARNING • Open the soundproof cover after making sure that the wheels have come to a complete stop. • Release the chuck by pressing after making sure that the wheels have come to a complete stop.

  • Page 70: Ex Lens Flat (Rimless) Edging Mode

    4 - 38 4.6.2.2 EX lens flat (rimless) edging mode This is a mode to perform the lens shape measurement of the front surface and flat edge an EX lens more accurately. (In the normal flat edging mode, the lens shape measurement of EX lens cannot be made.) Especially, this mode is effective when the polishing is selected to obtain the polishing with high accuracy.
  • Page 71 4 - 39 5. Remove the lens. WARNING • Open the soundproof cover after making sure that the wheels have come to a complete stop. • Release the chuck by pressing after making sure that the wheels have come to a complete stop.

  • Page 72: Other Processings

    4 - 40 4.6.3 Other processings 4.6.3.1 Processing for frame changing 1. Trace new frames. 2. Call up the traced data. Press The traced outline of the frames will appear on the display. 3. Establish the frame changing mode. Press FC will appear at the bottom right of the display.
  • Page 73 4 - 41 5. Set the lens to the pattern setting unit while White button pressing the white button. Align the top mark on the cup with the direction of the white button. 6. Trace the lens in the same manner as Steps 2 - 4 of “4.3.2 Tracing pattern”.
  • Page 74 4 - 42 9. Remove the lens with the lens cup from the pattern setting unit. 10. Edge the lens. Processing will not start if it is judged that the lens size is not enough for processing in the lens shape measurement* 11.

  • Page 75: Processing Half-Eye Lens

    4 - 43 4.6.3.2 Processing half-eye lenses When the distance from the blocking point to the position of edge-to-be is short and the lens adapter or lens clamp may contact with the wheels, the mark of the optical center will change from indicates, replace the lens adapter, lens clamp and lens cup with the ones for half-eye lens by the following procedure.
  • Page 76 4 - 44 3. Block the lens with the half-eye lens cup. 1) Stick a provided double-coated adhesive tape for half-eye lens to the half-eye lens cup. (Double-coated adhesive tape for half-eye lens is supplied only for the NIDEK type.) If you use the conventional double-coated adhesive tape, cut off the excess part along the edge of the cup.
  • Page 77 4 - 45 WARNING • Be sure to keep the soundproof cover closed while processing a lens. If the soundproof cover is opened during processing, the instrument does not stop. Spray including processing waste may cause eye damage. 6. Start processing. Press NOTE •...

  • Page 78: Polishing (Type Pl4, Plb, And Plb-2R)

    4 - 46 4.6.3.3 Polishing (Type PL4, PLB, and PLB-2R) This is a mode to polish the lens edge to save your time required to buff the lens edge after the finishing. Set “POL” by pressing before starting processing with NOTE •...

  • Page 79: Glass Soft Processing

    4 - 47 4.6.3.4 Glass soft processing Displayed only when the soft processing mode is selected. This is the processing method to perform the roughing process more precisely. Even though the processing time is extended a little, lens breakage is prevented. When glass lenses are broken during processing, select the soft processing mode to prevent them from breaking.

  • Page 80: Inputting Frame Tilt Angle In Flat Edging

    4 - 48 4.6.3.5 Inputting the frame tilt angle in flat edging To increase the finished PD accuracy, correction is made using the frame tilt angle measured during tracing. For nylor or two-point frames, however, the frame tilt angle cannot be measured because the pattern is traced.

  • Page 81: Checking Lens Size

    4 - 49 4.7 Checking the Lens Size Check the lens size after processing is completed. If the lens is too large, retouch it to correct the size. 4.7.1 Checking the lens size Fit the lens in the frame and measure the gap at the rim joint. NOTE •...
  • Page 82 4 - 50 NOTE • In the retouching process, reducing the lens size in 0.5 mm or more may lessen its vertical width. Therefore, in the trial processing, process a lens with its size 3 mm larger. In the actual processing, do not perform retouching but follow the instructions below beginning with roughing.

  • Page 83: Processing The Opposite Lens

    4 - 51 4.8 Processing the Opposite Lens 1. Change the lens to be processed. Press to switch the lens to be processed. 2. Process the opposite lens in the same manner. 4.9 Removing the Lens Cup When removing the suction cup or lens cup, use the provided cup remover. Insert the cup remover into the lens cup, and remove the lens cup while prying the cup with the remover.

  • Page 84: Treatment After Daily Use

    4 - 52 4.10 Treatment after Daily Use 1. Clean the processing unit. Follow Steps 1 - 4 in “8.1 Wheel Dressing” to water the processing unit and wash out the processing wastes with a brush. CAUTION • Be careful not to let water go into the inside of the instrument. It may cause malfunction of the instrument.

  • Page 85: Daily Checks

    4 - 53 4.11 Daily Checks 4.11.1 Daily check before use Check the followings before each use of the day. It is recommended to provide a check list to make sure everything is checked. A. Is the wheel proper? Check if there is no fracture, crack or flaw on the wheel. CAUTION •...

  • Page 86: Daily Check After Use

    4 - 54 4.11.2 Daily check after use Check the followings after every use each day. It is recommended to provide a check list to make sure everything is checked. A. Is the power turned OFF? B. Is the processing unit well cleaned? C.

  • Page 87: Periodical Check

    4 - 55 4.12 Periodical Check It is recommended to perform the periodical inspection every two years to use the instrument for a long time under a normal condition. On the periodical inspection, performance check of the whole system, etc. and replacement of maintenance parts are done. If the inspection is required, contact NIDEK or your authorized distributor.

  • Page 88: Other Functions

    OTHER FUNCTIONS § 5 5.1 Process Counter This function displays the count for lenses that have been processed since production for each lens material. Besides, the count of polished lenses is displayed as well. 1. Call up the MENU display. Press 2.

  • Page 89: Parameter Settings

    5 - 2 5.2 Parameter Settings This function sets each parameter according to the operator’s use. 1. Call up the MENU display. Press 2. Call up the Parameter exchange mode display. Press again. 3. Select the item whose parameter needs to be changed.
  • Page 90 5 - 3 [Parameter items and the setting contents] 1) Size preset (PLA, MTL) : ± 2) Size preset (PLA, CEL or ZYL) : ± 3) Size preset (GLS, MTL) : ± (not function for Type PLB) 4) Size preset (GLS, CEL or ZYL) : ±...
  • Page 91 5 - 4 10) Ext. interface: None, STD., RS232, LAN, ExLAN, MGNET, BK/LE, NAVIS, DVI, VCA-A, VCA-B Factory setting: NAVIS Selects whether or not to communicate with an external instrument and sets the communication format. Only when “None” is selected, the memory function becomes available. STD.: NIDEK standard format.
  • Page 92 5 - 5 14) Data Transfer : NON, VALUE, MATER, POLIS, BF, ALL Factory setting: NON Selects the kinds of data that the edger does not accept when receiving the data from an external device. The selected data in the parameter will be transmitted, but not accepted by the edger.
  • Page 93 5 - 6 20) Meas. after roughing : None, All, PLA Factory setting: None Sets the function that remeasures lens shape after roughing. None: After roughing, the lens shape is not remeasured. All: Except when the lens material is set to “GLS” (glass), the lens shape is remeasured after roughing.

  • Page 94: Storing Initial Display

    5 - 7 5.3 Storing Initial Display This function stores the following items on the Layout display as the initial display which appears just after power-up. If the factory-set items on the initial display do not satisfy the operator’s need, it is possible to change the items to be displayed and restore them.

  • Page 95: Storing And Calling Up The Traced Data

    5 - 8 5.4 Storing and Calling Up the Traced Data The edger is provided with a memory function, which stores traced data and lens layout data in its memory and calls them up whenever necessary. By storing a repetitive lens outline as a standard data and calling it up with the function, an operator does not have to trace the same lens for each edging and can save required time for lens processing.

  • Page 96: When The Edger Is Not Connected To The Barcode Scanner

    5 - 9 5.4.1 When the edger is not connected to the barcode scanner The internal memory built in the standard type of the instrument can store and manage the traced outline and lens layout data of 100 sets of frame. <Storing method>...

  • Page 97: When The Edger Is Connected To The Barcode Scanner

    5 - 10 5.4.2 When the edger is connected to the barcode scanner By connection of the edger to the optional barcode scanner, the barcode memory function, which stores traced outline and lens layout data for a maximum of 500 sets of frame, becomes available. The read barcode number is stored as the managing number of the data.
  • Page 98 5 - 11 <Method for calling up> To only store the traced outline and not storing the lens layout data, set the “Layout memory” parameter to “None” in advance (see p. 5-4). 1. Read the barcode of the frame whose data to be called up.

  • Page 99: Troubleshooting Guide

    TROUBLESHOOTING GUIDE § 6 In the event that the instrument does not work correctly, correct the problem according to the following table before contacting NIDEK or your authorized distributor. Symptom Action The display is not shown though the Replace fuses. See "8.4 Replacing Fuses" (p. 8-11). power is turned ON.

  • Page 100: Storage

    STORAGE § 7 NOTE • Store the instrument in an environment free from dust and direct sunlight. Avoid storing instrument in humid surroundings. • If the instrument will not be used for a long time, unplug the power cable from the wall outlet.

  • Page 101: Maintenance

    MAINTENANCE § 8 8.1 Wheel Dressing A clogged wheel requires a longer time for processing and makes the finished size inaccurate. It is necessary, therefore, to regularly dress the wheels. CAUTION • In the dressing mode, the cover sensor is released and the wheels turn with the soundproof cover open.
  • Page 102 8 - 2 3. Open the soundproof cover. 4. Start dressing. CAUTION • Apply the end surface of the dressing stick to the wheel, not the corner or the edge. Otherwise, the wheel may be damaged. • Hold the dressing stick with both hands. If the stick is held with one hand, the stick cannot be held strongly enough, the corner of the stick may collide with the wheel and damage it.
  • Page 103 8 - 3 [Dressing the polishing wheel] 1) Press Water will run for a few seconds and the wheels will begin to turn at the same time. 2) Wet the dressing stick well with running water. 3) Press to stop the water. 4) Apply the dressing stick gently to the turning wheel.

  • Page 104: Replacing The Water And Filter (115 V Regions)

    8 - 4 8.2 Replacing the Water and Filter (115 V regions) The procedure differs depending on whether the optional FP-100 is equipped or not. 8.2.1 Replacing the water (when the optional FP-100 is equipped) Replace the processing water and stocking filter in the tank periodically. It is recommended that the water be replaced for every 100 lenses processed.
  • Page 105 8 - 5 6. Filter the processing water to separate the processing waste and water. 1) Connect the special hose of the FP-100 to the filter joint on the tank. Press into the hose until you hear it click. 2) Set the function lever on the FP-100 to “FILTER”. 3) Turn on ( | ) the power switch on the FP-100.
  • Page 106 8 - 6 10. Put the water into the tank up to the position Drain pipe connector illustrated in the right figure. Even when the filtered water is reused, add required water. Guide of water volume 11. Put the lid on the tank. 12.

  • Page 107: Replacing The Water (When The Optional Fp-100 Is Not Equipped)

    8 - 7 8.2.2 Replacing the water (when the optional FP-100 is not equipped) Replace the processing water and stocking filter in the tank periodically. It is recommended that the water be replaced for every 100 lenses processed. NOTE • When the message “Please Clean Tank & Pump and Replace Filter” appears and the processing is stopped, replace the processing water and remove the waste accumulated on the drain pipe connector.
  • Page 108 8 - 8 8. Put the water into the tank up to the position Drain pipe connector illustrated in the right figure. NOTE Guide of water volume • Do not put a plastic sheet in the tank. The pump fill may be blocked and it may cause malfunction.

  • Page 109: Replacing The Water And Filter (230 V Regions)

    8 - 9 8.3 Replacing the Water and Filter (230 V regions) Replace the processing water and stocking filter in the tank periodically. It is recommended that the water be replaced for every 100 lenses processed. NOTE • When the “Please Clean Tank & Pump and Replace Filter” message appears and the processing is stopped, replace the processing water and stocking filter, and remove the waste accumulated on the drain pipe connector.
  • Page 110 8 - 10 9. Put the water into the tank. Put the water up to 80% (about 5 cm from the top). The waste disposal becomes easier by spreading a plastic sheet in the tank in advance. 10. Attach a new stocking filter. Rubber band Pass the stocking filter from the inside of the cover into the metal fitting and hold it with a...

  • Page 111: Replacing Fuses

    8 - 11 8.4 Replacing Fuses If the instrument can not be activated though the power switch is turned ON, fuse may be blown out. Replace the fuses with new ones. CAUTION • Be sure to turn OFF the power switch and pull out the power cable before replacing fuses.

  • Page 112: Size Adjustment

    8 - 12 8.6 Size Adjustment When a edged lens is mounted into frames, the lens size is not fit all the time. In such cases, adjust the size by inputting the compensation value as follows. 1. Call up the MENU display. Press 2.

  • Page 113: Adjusting Bevel Position

    8 - 13 4. Go back to the Layout display. Press 5. Repeat Steps 1 - 4 until the lens size just fits the frame. 8.7 Adjusting Bevel Position When the bevel of a lens is finished to be displaced from the designated position, adjust the bevel position by changing the bevel constant.
  • Page 114 8 - 14 3. Call up the Bevel adjustment display. Align the pointer ( ) to “Bevel adjustment” and press 4. Input the compensation value. To shift the bevel toward the front side of the lens, press To shift toward the rear side, press The arrow shows that the bevel is moved toward the front side, and...

  • Page 115: Adjusting Axis Shift

    8 - 15 8.8 Adjusting Axis Shift 8.8.1 Adjusting axis shift when polishing is not done When the axis angle of a lens is finished to be shifted from the designated angle, adjust it as follows. 1. Call up the MENU display. Press 2.
  • Page 116 8 - 16 4. Go back to the MENU display. Press 5. Go back to the Layout display. Press twice. 6. Repeat Steps 1 - 5 until the correct axis angle is obtained.

  • Page 117: Adjusting Lens Margin Allowed For Finishing

    8 - 17 8.9 Adjusting Lens Margin Allowed for Finishing The lens margin is compensated by the following procedure. 1. Call up the MENU display. Press 2. Call up the Size adjustment display. Align the pointer ( ) to “Size adjustment” and press 3.

  • Page 118: Pd Adjustment

    8 - 18 4. Go back to the MENU display. Press 5. Go back to the Layout display. Press twice. 8.10 PD Adjustment If the PD value inputted on the layout display does not agree with the PD of the finished lens, adjust the PD amount of the finished lens by the following procedure.

  • Page 119: Adjustment For Polishing

    8 - 19 8.11 Adjustment for Polishing 8.11.1 If a part of edge is left unpolished (Type PL4, PLB, and PLB-2R) 1. Call up the MENU display. Press 2. Call up the Size adjustment display. Align the pointer ( ) to “Size adjustment” and press 3.
  • Page 120 8 - 20 4. Go back to the MENU display. Press 5. Go back to the Layout display. Press twice. 6. Repeat Steps 1 - 5 until the whole edge is polished evenly. * 7. Check the finished size after polishing. Check each material lens for beveling and flat edging (only flat edging of Type PL4).
  • Page 121 8 - 21 3) Align the pointer ( ) to the desired item with To adjust the beveled lens margin, specify as follows: For plastic or acrylic resin lenses, select “Polish size (PLA, bevel)”. For polycarbonate or trivex lenses, select “Polish size (PC, bevel)”. For high index plastic lenses, select “Rough size (HPL, bevel)”.

  • Page 122: If The Front Edge Or Rear Edge Is Left Unpolished (Type Plb And Plb-2R)

    8 - 22 8.11.2 If the front edge or rear edge is left unpolished (Type PLB and PLB-2R) The polished bevel position is adjusted by the following procedure. 1. Call up the MENU display. Press 2. Call up the Size adjustment display. Align the pointer ( ) to “Bevel adjustment”...

  • Page 123: Axis Shift Adjustment For Polishing (Type Pl4, Plb, And Plb-2R)

    8 - 23 8.11.3 Axis shift adjustment for polishing (Type PL4, PLB, and PLB-2R) If the lens edge is not polished completely even after adjustment is made with “POL Differential”, the axis angle may be shifted. Perform the adjustment of the axis angle by the following procedure. 1.
  • Page 124 8 - 24 e.g. 1 At the sight from the front of lens, the upper left side is not polished, add 0.50 to the present value. Setting value: +1.00 +1.50 e.g. 2 At the sight from the front of lens, the upper right side is not polished, subtract 0.50 from the present value.

  • Page 125: Tracer Calibration

    8 - 25 8.12 Tracer Calibration Perform calibration of the tracer using the provided standard frames or standard pattern. It is recommended to perform calibration at the time of start to ensure the accuracy of tracing. If an error occurs in circumference, also perform calibration. 1.

  • Page 126: List Of Consumable Articles

    8 - 26 Circumference 6) Check traced data (circumference) on the MENU display. Circumference: If it is not in the range of 162.83±0.05, perform calibration with the standard frames again. 7) Remove the standard frames. 2. Perform calibration with the standard pattern. 1) Set the provided standard pattern into the tracer.

  • Page 127: Specifications

    SPECIFICATIONS § 9 Processing system Beveling Auto: Computer-calculated bevel Guided: Manual bevel setting, which enables you to select either the curve profiling the front surface, the curve profiling the rear surface, the specified curve value, the position ratio or tilting amount Flat (rimless) edging Flat edging Polishing...
  • Page 128 9 - 2 Processing pressure Approx. 4.5 kg (fixed) Wheels Type PC Roughing wheel for plastic lens: 100 mm in diameter, 22 mm in width Roughing wheel for glass lens: 100 mm in diameter, 17 mm in width Finishing wheel: 100 mm in diameter, 23 mm in width Type PL4 Roughing wheel for plastic lens:...
  • Page 129 9 - 3 Water supply system Pump circulation Other functions Layout: Active, passive, bifocal Layout input item: FPD (DBL) PD (1/2 PD) Vertical layout * Eye point layout function is available. Retouching function: Available (Memory function is available.) Frame memory function: Standard storable data 100 sets * The optional barcord scanner allows up to 500 sets of data to be stored.
  • Page 130 9 - 4 Whole system Dimensions: 520 (W) × 484 (D) × 330 (H) mm (only main body) Weight: 42 kg (only main body) Power supply: A. AC115 V 50/60 Hz B. AC230 V 50/60 Hz (Main supply voltage fluctuation should not exceed ±10% of the nominal voltage.) * Each setting of A and B is set in factory.

  • Page 131: Accessories

    ACCESSORIES § 1 0 10.1 NIDEK-type Accessories Operator’s manual .................. 1 pc. Suction cup .................... 3 pcs. Lens cup ....................5 pcs. Double-coated adhesive tape ..............1 sheet Dressing stick for roughing wheel (WA80K) ........1 pc. (except for PLB) Dressing stick for finishing wheel (WA320K) ........

  • Page 132: Santi-Type Accessories

    10 - 2 10.3 SANTI-type Accessories Operator’s manual .................. 1 pc. Double-coated adhesive tape ..............1 sheet Dressing stick for roughing wheel (WA80K) ........1 pc. (except for PLB) Dressing stick for finishing wheel (WA320K) ........1 pc. Dressing stick for polishing wheel (WA4000) ........1 pc. (except for PC) Half-eye lens clamp ................

  • Page 133: Appendix Asupplement

    SUPPLEMENT APPENDIX A A.1 Selection of Tracing (1) Tracing frames Normal tracing Tracing one rim only Tracing both rims Tracing single rim Set frames into the tracing unit. Set frames into the tracing unit. Press Press See "4.3.1.1 Tracing both rims" (p. 4-4). See "4.3.1.2 Tracing single rim"...
  • Page 134 A - 2 (2) Tracing pattern or dummy lens Tracing pattern Tracing dummy lens Pattern tracing Dummy lens tracing Set a pattern to the tracing unit. Set a dummy lens to the tracing unit. Press Press See "4.3.3 Tracing dummy lens." See "4.3.2 Tracing pattern"...

  • Page 135: Selection Of Layout

    A - 3 A.2 Selection of Layout (1) Layout forms Normal input Inputting monocular PD (1/2PD) Optical center 1/2PD 1/2PD Optical center This is a form to input FPD, PD and the This is a form to input the distance from height of optical center from the center the frame bridge center to each eye of the rim (...

  • Page 136: Selection Of Blocking

    A - 4 (2) Selection of lens and layout Bifocal lens Progressive power lens See "4.4.2.2 Layout of progressive See "4.4.2.1 Layout of bifocal lens" power lens" (p. 4-16). (p. 4-15). A.3 Selection of Blocking Active mode Passive mode H o r i z o n t a l l y d e c e n t e r i n g amount V e r t i c a l l y...

  • Page 137: Selection Of Processing

    A - 5 A.4 Selection of Processing (1) Processing mode Adjusting bevel position Creating computer-calculated bevel Guided processing mode See "4.6.1.1 Auto processing mode" Select "GUI". (p. 4-22). Press Check the Bevel simulation display. Creating bevel on EX lens Adjust the bevel curve and bevel position.
  • Page 138 A - 6 (2) Special processing Processing a lens, which has already Finished lens size is too large for been mounted on one frame, in order to frame fit it into another frame. Retouching Processing for frame change Change the size value. Trace frames.

  • Page 139: Appendix Berror Code

    ERROR CODE APPENDIX B The instrument is provided with the self-diagnostic function that monitors operations all the time. When any failure occurs in the instrument, it will stop automatically and show the error code on the display panel. In an event of failure, inform the error code as well as the symptoms of the instrument. The error code is essential to proper repair work.
  • Page 140 B - 2 ERROR CODE CONTENTS 0801 CPU false interrupt error. 0802 CPU address error. 0803 CPU DMA bus error. 0900 Error in writing of EEPROM. 0901 Size constant in rough edging is out of its specified range. 0902 Size constant is out of its specified range. 0903 Bevel constant is out of its specified range.

  • Page 141: Appendix Cglossary

    GLOSSARY APPENDIX C In this manual, the following terms are used to provide an easy understanding of the contents. Therefore, thoroughly understand before reading the contents of this manual. Active mode This is for blocking a lens at the optical center. Auto processing mode In this mode, the bevel curve and bevel position are automatically calculated by the computer for their best values of processing.
  • Page 142 C - 2 Half-eye lens processing For the frame whose vertical diameter is short, the mark of the optical center becomes , and as soon as processing starts, the “Use chuck for half-eye lens” message will appear and the instrument will stop temporarily. These indications mean that the lens adapter or lens clamp may contact with the wheels.
  • Page 143 INDEX Active mode ..........4-18 Glass soft processing ........ 4-47 Adjusting axis shift ........8-15 Guided processing mode ......4-25 Adjusting bevel position ......8-13 allowed for finishing ......8-12 Auto-correction of FPD ......4-36 In a case that the stylus cannot be set in the groove automatically ......
  • Page 144 Index - 2 Ratio ............4-26 Rear base curve ......... 4-26 Replacing water .......... 8-5 Retouching lens ........4-49 Rim clips ............. 3-5 Roughing wheel for glass lens ....3-4 RS-232C interface connector ...... 3-2 Sectional view position line ........4-25, 4-33 Semiauto tracing .........

Table of Contents
