NIDEK
SYSTEM EDGER
SE-9090 Express
INSTALLATION MANUAL
This manual is packed with the system for convenience when service persons install the
system.
The contents are unnecessary for customers to use the system, so be sure not to perform
the operations in this manual. The system may not work properly if settings are changed
carelessly.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE-9090 Express and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nidek Medical SE-9090 Express

Summary of Contents for Nidek Medical SE-9090 Express

  • Page 1 NIDEK SYSTEM EDGER SE-9090 Express INSTALLATION MANUAL This manual is packed with the system for convenience when service persons install the system. The contents are unnecessary for customers to use the system, so be sure not to perform the operations in this manual. The system may not work properly if settings are changed...
  • Page 2 NIDEK CO., LTD. : 34-14, Maehama, Hiroishi-cho, Gamagori, Aichi 443-0038, Japan (Manufacturer) Telephone: (0533) 67-6611 Facsimile: (0533) 67-6610 NIDEK CO., LTD : 6th Floor, Takahashi Bldg., No.2, 3-chome, Kanda-jinboucho (Tokyo Office) Chiyoda-ku, Tokyo 101-0051, Japan Telephone: (03) 3288-0571 Facsimile: (03) 3288-0570 Telex: 2226647 NIDEK J NIDEK INCORPORATED : 47651 Westinghouse Drive, Fremont, California 94539, U.
  • Page 3 For safe installation BEFORE INSTALLATION, READ THIS MANUAL. This manual provides precautions, procedures, and adjusting methods for installing the NIDEK SYSTEM EDGER Model SE-9090 Express. Before installation, read and understand this manual and the operator’s manual thoroughly. Safety precautions In this manual, Signal Words are used to designate a degree or level of safety alerting. The definitions...
  • Page 4 Installation precautions WARNING Never touch the grinding wheel when it is turning. • You may be injured. If abnormal conditions such as cracks are found on the grinding wheel, • stop using the system immediately. The wheels may break and broken pieces may injure personnel if used with such flaws.

  • Page 5: Table Of Contents

    4. CHECK LIST ........15 4.1 SE-9090 Express Installation Work Check List .

  • Page 7: Requirements

    REQUIREMENTS Requirements • Hexagonal wrench (accessory) for installation • Wrench (size 16 mm) for installation • Phillips screwdriver (No.0) for installation • Flatblade screwdriver (blade width 6 mm) for installation • Centering device for adjustment • Test lens for adjustment CR39 SPH: -3.00 to -5.00D 6 pieces CR39 SPH: approx.
  • Page 8 REQUIREMENTS: Requirements...

  • Page 9: Installation Procedure

    INSTALLATION PROCEDURE Unpacking Remove the cloth belt (n = 2) that fixes the outer case. Remove the packing tape that holds the cloth belt and pull the end of the cloth belt on which a label is attached to the direction as shown on the right.
  • Page 10 INSTALLATION PROCEDURE: Unpacking Remove the plastic bag from the main body. Remove the brackets (n = 4) that hold the Upper nut adjuster feet (n = 4). 1) Loosen the upper nut of the adjuster foot from the bracket. 2) Remove the bolts (n = 2) and washers (n = 2) to remove the bracket.
  • Page 11 INSTALLATION PROCEDURE: Unpacking Open the tank box and remove the contents. Feedwater hoses (n = 2) [Contents of the tank box] Drain pipe Feedwater hose (2 pcs.) Drain pipe Pump (2 pcs.) Accessories Stocking filter (20 pcs.) Pump boxes Tank (n = 2) Accessories Hose band-S (2 pcs.)

  • Page 12: Pipe Arrangement

    INSTALLATION PROCEDURE: Pipe Arrangement Pipe Arrangement Connect the pump and the tank to the main body. The following describes one pump as “PUMP 1” and the other pump as “PUMP 2”. Connect the couplers to the ends of the feedwater hoses (n = 2). 1) Pass the hose band-S to the end of the feedwater hose on which there is no connector.
  • Page 13 INSTALLATION PROCEDURE: Pipe Arrangement Screw the drain pipe into the cuff. Cuff Drain pipe Insert PUMP 1 and PUMP 2 into the two openings on the tank cover. Put the end of the drain tube around here (step 11). Connect the drain pipe to the outlet at the underside of the main body. 1) Pass the hose band-L to the drain pipe.
  • Page 14 INSTALLATION PROCEDURE: Pipe Arrangement Connect the duct (only when the vacuum system is connected). 1) Attach the duct adapter (1 pc.) to the air inlet/outlet at the rear side of the main body. 2) Connect the duct to the duct adapter, and fix the hose band. 3) Connect the other end of the duct to the vacuum system.

  • Page 15: Check/Adjustment Procedure

    CHECK/ADJUSTMENT PROCEDURE Outline of Check/Adjustment Procedure • Processing conditions may vary with the transport/setting conditions of the system. Check and adjust the processing conditions, and complete the check list (copy of Sec. 4). 1. Size adjustment 2. Bevel position adjustment 3.
  • Page 16 CHECK/ADJUSTMENT PROCEDURE: Size Adjustment Recall the 45 built-in data and process a polycarbonate lens in the beveling mode and ∅ flat edging mode, and then check the sizes. Adjust the size. 1) Recall the MENU screen. Press the [MENU] button on the Layout screen.

  • Page 17: Adjusting Bevel Position

    CHECK/ADJUSTMENT PROCEDURE: Adjusting Bevel Position Adjusting Bevel Position When the bevel of a lens is shifted from the designated position, adjust the bevel position by changing the parameter value. Check the bevel position. 1) Recall the ∅45 built-in data, and process a lens of SPH: approx.
  • Page 18 CHECK/ADJUSTMENT PROCEDURE: Adjusting Bevel Position 4) Change the parameter value. Decrease the value. Increase the value. After inputting values using the displayed numeric keypad, press the [ENT] button. ⇒ Increase the value The bevel is shifted to the front surface of the lens. ⇒...

  • Page 19: Final Check

    CHECK/ADJUSTMENT PROCEDURE: Final Check Final Check ○ Safety bevel check Perform chamfering and have the user check the chamfered amount. Depending on the user’s needs, change the setting on the SFB Setting screen. See “Setting Parameters” of the operator’s manual for details. ○...
  • Page 20 CHECK/ADJUSTMENT PROCEDURE: Final Check...

  • Page 21: Check List

    CHECK LIST SE-9090 Express Installation Work Check List After the system is installed, record the results. Place check marks in the checkbox after checking items. Record the setting of the parameter to ( Is the installation place proper? Are the connections of PUMP 1 and PUMP 2 proper? Check the drain condition in the Dressing mode.
  • Page 22 CHECK LIST: SE-9090 Express Installation Work Check List Small SB Ratio Front, FLT At installation ( ) After adjustment ( Medium S.B. Offset Front, FLT At installation ( ) After adjustment ( Medium SB Ratio Front, FLT At installation (...

  • Page 23: Adjustment Display

    ADJUSTMENT DISPLAY The following shows parameters on each adjustment screen for Type PLB. For other types, the parameters may not be included or parameter names are different. See the operator’s manual for details. [Size adjustment screen] Press the [Size Adjustment] button on the MENU screen. Size Constant PLA, BVL Size Constant PLA, FLT Polish Size PLA, BVL...
  • Page 24 ADJUSTMENT DISPLAY: Pol. Differential PC, BVL Pol. Differential PC, FLT [Idle Rotation screen] Press the [Idle Rotation] button on the MENU screen. Finish Idle Rotation PLA Pol. Idle Rotation PLA, BVL Pol. Idle Rotation PLA, FLT Pol. Idle Rotation HI, BVL Pol.
  • Page 25 ADJUSTMENT DISPLAY: Small SB Ratio Front, BVL Medium SB Offset Front, BVL Medium SB Ratio Front, BVL Large SB Offset Front, BVL Large SB Ratio Front, BVL Special SB Offset Front, BVL Special SB Ratio Front, BVL Small SB Offset Front, FLT Small SB Ratio Front, FLT Medium S.B.
  • Page 26 ADJUSTMENT DISPLAY: Size Preset (PLA) Language Wheel Spec Machine Type [Process Speed screen] Press the [Process Speed] button on the MENU screen. Rough Process Speed PLA Finish Process Speed PLA Polish Process Speed PLA Rough Process Speed PC Finish Process Speed PC Polish Process Speed PC [Wheel Speed screen] Press the [>>] button on the Process Speed screen.
