4 Intended use

The Wilo pressure-boosting systems of series
ISAR MODH1 are designed for water supply sys-
tems for pressure boosting and pressure mainte-
nance.
They are used in:
• Drinking water installations, primarily in high-rise
apartments, hospitals, administrative and industrial
buildings, the structure, function and requirements
of which comply with the following
standards, guidelines and directives:
• Water Supply (Water Quality) Regulations 2018
Reg 4
• Industrial water supply and cooling systems
• Irrigation and sprinkling installations
Make sure that the fluid to be pumped in the
system will not corrode the materials used in the
system either chemically or mechanically and that
it does not contain any abrasive or long-fibre
constituents.
Automatically controlled pressure-boosting sys-
tems are supplied from the public drinking water
supply network (connected indirectly) via a break
tank. These break tanks are closed but are not
pressurised, i.e. they are under only atmospheric
pressure.

5.2 Technical Data

Max. volume flow
Max. delivery head
Speed
Mains voltage
Rated current
Frequency
Electrical connection
Insulation class
Protection class
Power consumption P1
Power consumption P2
Nominal Diameter:
Connection
Suction/pressure pipe
5

Product information

5.1

Type key

Example: Wilo-ISAR MODH1-1CH1-L-202/SCe
Wilo Brand name
ISAR Product family: pressure-boosting systems
MOD Application (commercial)
H With horizontal pumps
1 Product level
(1-entry, 3-standard, 5-premium)
-1 Number of pumps
CH1-L Pump series
2 Rated flow rate Q [m3/h] per pump
(2 pole – 50 Hz version)
02 Number of pump stages
/SCe Control device (Smart Control)
Example: Wilo-ISAR MODH1-3CH1-L-605/SCe
Wilo Brand name
ISAR Product family: pressure-boosting systems
MOD Application (commercial)
H With horizontal pumps
1 Product level
(1-entry, 3-standard, 5-premium)
-3 Number of pumps
CH1-L Pump series
6 Rated flow rate Q [m3/h] per pump
(2 pole – 50 Hz version)
05 Number of pump stages
/SCe Control device (Smart Control)
See catalogue/data sheet
See catalogue/data sheet
2800 – 2900 rpm (constant speed)
1~ 230 V ±10 % V (L1, N, PE)
See catalogue/data sheet
50 Hz
(See installation and operating instructions and circuit diagram of the control
device)
F
IP54 (pump by itself IPX5)
See rating plate of pump/motor
See rating plate of pump/motor
R1¼/R1¼
(ISAR MODH1-2CH1-L-2.../EC)
(ISAR MODH1-2CH1-L-4.../EC)
(ISAR MODH1-3CH1-L-2.../EC)
5
