LH72 Change of display resolution (polarity)
The operation method for changing the display resolution differs depending on the purpose and conditions of the change.
Select the purpose and conditions to be changed from the table below and perform the operation.
Purpose of change
Change the polarity for each input axis
while using the addition function
Change the measurement unit resolution
Change the display resolution
Change the display polarity
(Counting direction is reversed)
Diameter display (double count value)
* If you do not know the output resolution of the measurement unit, refer to the separate "Initial setup manual".
Basic settings ⇒ Addition display ⇒ Change
①
Set to basic setting mode.
Turn key "ON" while the AC adapter is energized.
Press and hold key for 3 seconds after the lamp changes from blinking to off.
The display will be
②
When the display is
Press key to select a condition.
When you have made your selection, press
To finish the basic settings, follow steps ③ and ④ below.
③
Switch from basic settings to normal count mode.
Press key once and the display will change to
Press key once and the display will change to
④
If you press key once, it will automatically enter the advanced setting mode and
Press key to enter normal count mode.
Operation
Basic settings ⇒ Addition display ⇒ Change
Basic setting ⇒ Measurement unit resolution ⇒ Change
Detailed settings ⇒ Display resolution ⇒ Change
Detailed settings ⇒ Display resolution ⇒ Change polarity
Detailed settings ⇒ Display resolution ⇒ Diameter display
. (additional display).
, press key to select the addition display.
key to save your settings.
.
.
LH72 Change of display resolution (polarity)
Change the selection of addition display in the basic
settings
Change the length measurement unit resolution in
the basic settings. And check the display resolution
in the detailed settings.
Change the display resolution in the detailed
settings
Change the display resolution in the detailed
settings
Change to diameter display with display resolution
in the detailed settings
LH72-3
Power ON
Addition display (input conditions to
be displayed on the Z axis)
display.
Ver.3 (2021.1) CS&S
Explanation
About 2 sec
Input 2
Input 3
Input 2 + Input 3
Input 2 - Input 3
Input 3 - Input 2
- (input 2 + Input 3)
1/3
