Magnescale LY72 Quick Start Manual

LY72 Change of display resolution (polarity)
The operation method for changing the display resolution differs depending on the purpose and conditions of the change.
Select the purpose and conditions to be changed from the table below and perform the operation.
Purpose of change
Change the measurement unit
resolution
Change the display resolution
Change the display polarity
(Counting direction is reversed)
Diameter display (double count value)
* If you do not know the output resolution of the measurement unit, refer to the separate "Initial setup manual".
Basic settings ⇒ Input axis ⇒ Change
①
Set to basic settings mode.
Turn key "ON" while the AC adapter is energized.
Press and hold key for 3 seconds after the lamp changes from blinking to off.
Power ON
②
When the display is
When the display is
The display will be
③
Press key of the axis you want to change and select
the measurement unit resolution.
When you have made your selection, press
④
Press key of the axis you want to change and select
the measurement unit resolution.
When you have made your selection, press
⑤
Switch from basic settings to normal count mode.
Press key once and the display will change to
Press key once and the display will change to
⑥
Press key once to automatically switch to advanced settings mode.
The display will be
Press key, the display becomes the normal display.
Operation
Basic settings ⇒ Input axis ⇒ Change
Advanced Settings ⇒ Display resolution ⇒ Change
Advanced Settings ⇒ Display resolution ⇒ Change polarity
Advanced Settings ⇒ Display resolution ⇒ Diameter display
About 2 sec
, press key three times.
, press key twice..
. (Measurement unit disassembly)
key to save your settings.
key to save your settings.
.
.
LY72 Change of display resolution (polarity)
LY72
When ABC is selected
in the label setting
Display example when inputting 3 axes
Input 1
Input 2
Input 3
.
Ver.1 (2021.1) CS&S
Explanation
Change the length measurement unit resolution
in the basic settings. And check the display
resolution in the detailed settings.
Change the display resolution in the detailed
settings
Change the display resolution in the detailed
settings
Change to diameter display with display
resolution in the detailed settings
When XYZ is selected
in the label setting
Selection of measurement
unit resolution
Standard
Extended key
Expansion
1/2
