Introduction - Expert EX-9132C-2 Operation Manual

We provide new ways of connecting legacy serial devices to a Local Area Network (LAN)
or Wide Area Network (WAN). TCP/IP converters are designed to operate serial ports over
100M bps Ethernet networks. The data is transmitted via TCP/IP protocol. Therefore,
control is available via Ethernet, Intranet and Internet. EX-9132C-2 converter is packaged in
a PVC material case well suited for industrial environments. It provides two serial ports one
is a RS-232 and another is RS-232/422/485 (Auto-Detect). All serial ports operate in
common industrial configuration.
EX-9132C-2 converter is a low-cost, high performance design. By carefully selecting high
quality with competitive prices components in the world, the products made network
connectivity possible with affordable cost for virtually all kinds of devices.
EX-9132C-2 is a full set converter device with two serial ports as one is a RS-232 port and
another is a RS-232/422/485 (Auto-Detect) and it provides one socket per connection port.
This operation manual will guide you step by step to learn the various functions of the
EX-9132C-2 converter. For support emal to support@d-d-s.nl
The following topics are covered in this chapter:
□
□ Overview
□
□
□ Block Diagram
□
□
□ Product Features
□
□
□ Product Specifications
□
