RS-422 Signals：Rx+ , Rx- , Tx+ , Tx- (Surge & Over Current Protect)
RS-485 Signals : Data+ , Data- (Surge & Over Current Protection)
Built-in RS422/RS485 Pull High-Low Resistor
Digital I/O Port
Digital TTL I/O * 8 pins
Socket Port Connection：1 Connection
15KV ESD for all signal
Watch Dog Function
Virtual Support Windows 2000 /2003 / XP / Vista / 7
Firmware On-line Updated Via Ethernet
Power：DC 9 – 24 V , 500mA
LED Lamp：
PWR (Green)
DATA (Red-Blink during data transferring and receiving)
LAN (Red for 10 Mbps ; Green for 100 Mbps)
SYS (Red-Blink)
Environment：
Operating Temperature：0℃∼70℃
Storage Temperature：-10℃∼80℃
Dimensions：115 * 90 * 27 mm ( W * D * H )
WEIGHT：140 gm
RoHS：Compliant with RoHS
Regulatory Approvals：FCC, CE
WARRANTY：1 year
