5 Port Pilot/Metal Seal
Body Ported
Series
Compact and Large Flow
Capacity: 491Nl/min
Small Power Consumption/
1.8W DC
VFS1320-D-01
VFS1120-G-01-F
VFS1220-E-01
VFS1120-G-01
JIS Symbol
2 position 3 position
Single Closed centre
Double Exhaust centre
Pressure centre
VFS1000
Model
Configuration Model
VFS1120
Single
2 position
VFS1220
Double
Closed
VFS1320
centre
Exhaust
VFS1420
3 position
centre
Pressure
VFS1520
centre
Note 1) According to JISB8375 (Once per 30 days) for the minumum operating frequency.
Note 2) According to JISB8375-1981. (The valve at supply pressure 0.5MPa.)
Note 3) In case of a grommet.
Note 4) The factors of "Note 1)" and "Note 2)" are achieved in controlled clean air.
Standard Specifications
Fuild
Max. operating pressure
Min. operating pressure
Proof pressure
Valve
Ambient and fluid temperature
Lubrication
Pilot valve manual override
Shock/vibration resistance
Protection structure
Rated voltage
Allowance voltage
Coil insulation
Apparent power
Solenoid
AC
(Power consumption)
Power consumption DC
Electrical entry
Note 1) Use dry air at low temperatures.
Note 2) Use turbine oil No.1 (ISO VG 32), if lubricated.
Note 3) Shock resistance: No malfunction on test using drop impact tester, to axis and right angle
directions of and armature main valve, each one time when energized and
deenergized. (Valve in the initial stage.)
Vibration resistance: No malfunction on test with 8.3 to 2000Hz, 1 sweep, to axis and right
angle directions of and armature main valve, each one time when
energized and de-energized. (Valve in the initial stage.)
Note 4) Based on JIS C0902.
Option Specifications
Manual override Non-locking push style (Extended), Locking style (Slotted), Locking style (Lever)
Voltage
Option
Foot bracket (with screw)
Note 1) No light for grommet but surge voltage suppressor (direct connecting lead wire) is
installed.
Manifold
Valve model
VFS120
VFS130
Note) VFS130: Manifold only. Cannot be used as a single unit.
Effective area Max. operating
Port size
2
(mm ) (Nl/min)
VFS1130 1 8
9.0 (491)
VFS1230 1 8
9.0 (491)
VFS1330 1 8
7.2 (393)
VFS1430 1 8
9.0 (491)
VFS1530 1 8 8.8 (481)
Air and inert gas
2 position
3 position
Not required
Non-locking push style (Flush)
Dust proof (protection level 0)
100V, 200V AC (50/60Hz), 24V DC
–15% to +10% rated voltage
Class B or equivalent
5.6VA (50Hz), 5.0VA (60Hz)
Inrush
Holding 3.4VA (2.1W)/50Hz, 2.3VA (1.5W)/60Hz
Note 5) Based on JIS C4003.
110 to 120V, 220V, 240V AC (50/60Hz)
12V, 100V DC
With indicator light and surge voltage suppressor
Part No. AXT626-10A, VFS1120 (single) only
Applicable manifold base (Pilot EXH)
Bar manifold (Individual EXH)
Bar manifold (Common EXH. base side)
Response Weight
(1) (2) (3)
cycle (CPM) time (ms) (kgf)
1200 15 or less 0.18
1200 13 or less 0.26
600 20 or less 0.27
600 20 or less 0.27
600 20 or less 0.27
1.0MPa
0.1MPa
0.15MPa
1.5MPa
o
(1)
–10 to 60 C
(2)
2 (3)
150/50m/s
(4)
(5)
1.8W
DIN connector
(1)
1.17-9
