Manor

Installation Guide

For Models:

MAN52ABZ5C4

MAN52AN5C4

4007498

net weight of fan: 23.59 lb. (10.7 kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the Ellington Manor and is the answer not in the manual?

Questions and answers

Summary of Contents for Craftmade Ellington Manor

Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Manor Installation Guide For Models: MAN52ABZ5C4 MAN52AN5C4 Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a 7 feet (76cm) clearance of 7 ft. (2.13m) from the floor and 30in. (2.13m) (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
Page 5 5. Fan Assembly (with downrod). stop pin set screw Remove hanging ball from downrod provided by loosening set screw on hanging ball. Remove pin and clip. Lower hanging ball and remove hanging ball stop pin. Then slide hanging ball off downrod. [Refer to diagram 1.] clip Loosen yoke set screws and nuts at top of motor...
Page 6: Fan Assembly. Pgs
5. Fan Assembly (with downrod). (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging ball rest on the hanging bracket.
Page 7: Wiring
7. Wiring. CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present. Make sure all electrical connections comply with Local Codes or Ordinances and the National Electrical Code. If you are unfamiliar with electrical white supply wire wiring or if the house/building wires are different ground...
Page 8: Blade Assembly
9. Blade Assembly. Time Saver: Washers for blade screws can be set on each blade screw prior to installing blades. motor housing Locate 15 blade attachment screws and washers in hardware pack. Hold blade arm up to blade and align holes. Insert 3 blade attachment screws plastic (along with washers) with fingers first and then motor...
Page 9: Testing Your Fan
10. Light Kit Assembly (Optional). (cont.) Connect BLACK (or BLUE) wire from switch housing to BLACK wire from light kit fitter. motor Connect WHITE wire from switch housing to housing WHITE wire from light kit fitter. Be sure that molex connections snap together securely. Align holes in light kit fitter with holes in switch housing.
Page 10: Troubleshooting
2. Verify that reverse switch is set completely in to arrange for return of fan. Return fan, shipping prepaid, to either direction. Craftmade/Ellington. We will repair or ship you a replacement fan, and we will pay the return shipping cost. 3. Check that fan is wired properly.
