Echelon
Installation Guide
For Model:
ECH54
WARNING
DC Motor will not operate
until blades are installed
E192641
net weight of fan: 17.86 lb (8.10 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 7
Warranty. pg. 13
page 1
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Echelon ECH54 and is the answer not in the manual?

Questions and answers

Summary of Contents for Craftmade Echelon ECH54

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Echelon Installation Guide For Model: ECH54 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.
  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
  • Page 3: Parts Inventory

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. Check against parts inventory that all parts have been included.
  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13 m) (76 cm) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. stop pin set screw Remove hanging ball from downrod provided by loosening set screw on hanging ball. Lower hanging ball and remove stop pin and then slide hanging hanging ball ball off of the downrod. [Refer to diagram 1.] Loosen yoke set screws and nuts at top of motor diagram 1 housing.
  • Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet wood ceiling joist box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with safety cable loop two hands. Slide downrod through opening in hanging bracket and let hanging ball rest on the hanging bracket.
  • Page 7: Wiring

    6. Wiring. WARNING: Turn off circuit breakers to current fixture white supply wire from breaker panel and be sure switch is turned to the ground OFF position. (green or bare) black supply wire CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present.
  • Page 8: Canopy Assembly

    7. Canopy Assembly. hanging Locate 2 screws on underside of hanging bracket bracket and remove screw closest to the open end of the hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded part of slotted hole in canopy screw over loosened screw in hanging bracket and canopy...
  • Page 9: Light Kit Assembly (Optional)

    motor 9. Light Kit Assembly (Optional). housing Remove 1 screw from motor plate on underside of motor housing and partially loosen the other 2 screws. Align slotted holes in center of fitter plate with loosened screws in motor plate, allowing molex connections from motor housing to come through hole in middle of fitter plate.
  • Page 10: Handheld Remote Control Assembly

    10. Handheld Remote Control Assembly. IN ORDER TO USE THE HANDHELD REMOTE remote CONTROL, PLEASE CONTINUE WITH SECTION 10 for control remote control assembly instructions. If you have cover already installed the wall control but do not wish to use the handheld remote control, please proceed to Section 11.
  • Page 11: Automated Learning Process./Activating Code

    11. Automated Learning Process./Activating Code. CAUTION: The wall and/or handheld remote control wall control can be programmed to multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. Restore electrical power and then, if using wall control, set slider switch on wall control to the ON position.
  • Page 12: Remote/Wall Control Operation

    12. Remote/Wall Control Operation. handheld wall control remote control IMPORTANT: Handheld remote control and wall III IV control must be SYNCHRONIZED with fan in order to properly function. Fan SPEED control buttons--1: Use to control the ceiling fan speed 1-6 Fan OFF button--2: Use to turn the fan off REVERSE function button--3:...
  • Page 13: Troubleshooting

    Service at 1-800-486-4892 to arrange for return of fan. properly. Return fan, shipping prepaid, to Craftmade. We will repair 3. Check to be sure fan is wired properly. or ship you a replacement fan, and we will pay the return 4.
