Summary of Contents for Broyhill Capilano A106004500
- Page 1 CAPILANO Capilano Pergola ASSEMBL Y INSTRUCTION ITEM#: A106004500 SKU#: 810452400 Need help? We are here for you! 1.866.578.6569 24/7 • Toll Free...
- Page 2 Safety Information This unit is heavy! Do not assemble DANGER: More than four people are required for this this item alone. assembly. Some parts may contain sharp edges. Wear Do not leave the gazebo where there WARNING: protective gloves. ...
- Page 3 TOOLS NEEDED IMPORTANT How many people needed for the installation work...
- Page 4 EXPLODED DRAWING...
- Page 5 Parts List Label Part Number Description Part Image P000200234 Post 1 P000200235 Post 2 P000200236 Post 3 P000200237 Post 4 P006100092 Base Cover P000100152 Base P005600124 Post Decoration P000400527 Arc Beam1 P000400528 Arc Beam2 P000400529 Short side beam P000400530 Long side beam Arc Beam P000500614 Connector...
- Page 6 P001100298 Canopy P005000207 Support Bar1 P005000208 Support Bar2 P002100177 table top...
- Page 7 Hardware Pack Label Part Number Description Part Image H06015C11 Bolt M6*15 Flat washer H19001C11 Bolt M6*45 H06045C11 Plastic Cup P91206A07001 Stake P12401A01001 Φ8*180 H00002C12 Wrench M6...
- Page 29 Care and Maintenance Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are scratched. This is not a defect and thus not covered by the warranty. ...
Need help?
Do you have a question about the Capilano A106004500 and is the answer not in the manual?
Questions and answers
I need assistance ordering replacement parts all 7 top cross bars. They they rusted and broke in less then a year
