- Page 1 ASSEMBLY INSTRUCTIONS ITEM# : GBO23-903 SKU# : 810580279 CRESTFIELD 3PC GLIDER SET Need help? We are here for you! 1-888-733-8169 Toll Free Or email us at customerservice_01@yeah.net,customerservice_02@yeah.net customerservice_03@yeah.net...
-
Page 2: Maintenance
GENERAL BEST PRACTICE FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to begin assembly Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its letter in the package Helpful hints provided along the way Retain these assembly instructions for future reference. -
Page 3: Parts List
PARTS LIST FOR 1 GLIDER: PARTS LIST Part No. Part Image Part No. Part Image Chair Back Bolt (M6x36mm) Seat Panel Frame Bolt (M6x41mm) Seat Panel Cloth Bolt (M6x44mm) Right Arm Washer Left Arm U-shaped Fitting Spring Washer Chair Base Seat Cushion Short Bolt (M6x28mm) Back Cushion... - Page 4 PRODUCT FRAME MAP STEP 1 STEP 2 PART REQUIRED: 6, 7 Keep the bolts loose.
- Page 5 STEP 2 STEP 2 PART REQUIRED: 2, 3 Keep the bolts loose. STEP 3 STEP 3 PART REQUIRED: 1 Keep the bolts loose.
- Page 6 STEP 4 STEP 4 PART REQUIRED: 5 Keep the bolts loose. STEP 5 PART REQUIRED: 4 Keep the bolts loose.
- Page 7 STEP 6 PART REQUIRED: 2, 6 & 7 Keep the bolts loose. STEP 7 PART REQUIRED: 16 & 17 Fully tighten all the bolts, then put the cushions (16) and (17) on the chair. Finished! Caution: To ensure one's safety during use of this swivel glider, make sure that all of the bolts are completely tightened. The chair has the ability to swivel and glider;...
- Page 8 PARTS LIST: PARTS LIST Part Image Part Image Part No. Part No. Table Top Short Bolt (M6x20mm) Table Support Long Bolt (M6x31mm) Table Leg Washer Tool STEP 1 PART REQUIRED: 1 & 2PC 3 Keep the bolts loose.
- Page 9 STEP 2 STEP 2 PART REQUIRED: 2 Tighten all bolts by using the supplied Tool. STEP 3 STEP 3 Warranty One year limited warranty. Proof of purchase (dated register receipt) is required for warranty claims. It remains the customer's responsibility for freight and packing charges to and from the service center.
