1-3 Mainboard Layout

1-4 Connector and Jumper Reference Chart

Jumper &
Connector No.
Power Supply
FAN2/FAN3
JP9/JP10
IR Infrared connector
CN1 CD-ROM audio in connector
Keyboard lock & Power indicator LED connector
System reset switch connector
Speaker connector
CN9
Green switch & Green LED connector
IDE activity LED connector
Over-ride power button
CN10 WOL(Wake-on-LAN) connector
ATX Power supply connector
FAN1 CPU cooling fan connector
System cooling fan connector
JP2 Host bus frequency jumper
JP3 On Board audio codec jumper
JP4 System lockup recovery jumper
JP5 CMOS setting
JP6 CPU frequency ratio
JP8 Chassis intrusion detection
Audio Line out and Speaker out Jumper
Ports PS/2 mouse and keyboard ports
Ports USB (Universal Serial Bus) ports
Function
Introduction
Page
13
16
12
13
13
13
13
12
17
11
14
14
15
15
15
16
15
16
16
14
17
5
