- Page 1 5.1 Channel Soundbar with Wireless Subwoofer and Speakers MODEL: ADDSB-0122 User Manual AFTER SALES SUPPORT tempo.org/support 1300 002 534 MODEL: ADDSB-0122 PRODUCT CODE: 708016 01/2022...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome Operation General Operation Unpack and Prepare Input Modes What's in the Box Bluetooth ® Wall Mount Installation Kit Installation Pairing Bluetooth Devices ® Wall Mounting Instructions (Soundbar) Bluetooth Playback ® Wall Mounting Instructions (Rear Speakers) Troubleshooting Connect to Power Specifications Controls and Connections Compliance and Responsible Disposal... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the Box Before setting up your new Soundbar, check you have everything: A. 5.1 Channel Soundbar B. Wireless Subwoofer C. Wireless Rear Speakers (2) D. Remote Control E. AAA Activ Energy Batteries (2) F. AC Adaptors (3) G. -
Page 5: Wall Mount Installation Kit
Wall Mount Installation Kit The illustration below shows the contents of the wall mount installation kit. These are the parts you will need if wall mounting your soundbar and rear speakers. • Place the Soundbar on a level surface. • Place the Soundbar away from any source that may generate heat or vibrations. -
Page 6: Installation
Installation This soundbar along with the rear speakers can sit free-standing on a surface, or it can be mounted to a wall. Note: The subwoofer cannot be wall mounted. Place on a secure, flat surface. Make sure the soundbar is standing on its rubber pads (on the left and right sides of the soundbar) and no other area of the bottom of soundbar is touching the surface. - Page 7 Wall mounting instructions are on the following pages. • Wall-mounted installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury and property damage! If you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing, which may be hidden inside or behind the wall.
-
Page 8: Wall Mounting Instructions (Soundbar)
Wall Mounting Instructions (Soundbar) Fix the supplied metal brackets to the bracket fixing holes on the back of the soundbar with the supplied short screws. Affix the brackets as shown in the illustration (left). Use a pencil to make drill hole marks on the wall for the plastic anchors. - Page 9 Slide the soundbar onto the fixed screws. Make sure that the soundbar is secure and attached firmly to the wall. For a concrete or brick wall: Insert the supplied plastic anchors into the holes and push in until they are flush with the wall. Drive the supplied long screws into the plastic anchors and tighten until the screw head is approximately 3mm from the wall.
-
Page 10: Wall Mounting Instructions (Rear Speakers)
Wall Mounting Instructions (Rear Speakers) Use a pencil to make drill hole marks on the wall for the plastic anchors at the desired mounting location. Make sure the marks are level before drilling. Use a 6mm bit and power drill (not 740mm supplied) to drill holes on the marks. - Page 11 Slide the rear speakers onto the fixed screws. Make sure that the rear speakers are secure and attached firmly to the wall. UNPACK AND PREPARE | 11...
-
Page 12: Connect To Power
Connect to Power Make sure the power switch is switched off at the power outlet until you have finished connecting your cables. Soundbar Rear Speakers Subwoofer The soundbar must use the 20VDC, 1.8A adaptor and the rear speakers must use the 20VDC, 1.2A adaptors. 12 | UNPACK AND PREPARE... -
Page 13: Controls And Connections
Controls and Connections Get to know your Soundbar Front Remote control sensor LED display Buttons on the Soundbar : Tap to turn on. Tap to put in Standby mode. : Tap to select your preferred input source. : Tap to decrease the volume level. : Tap to increase the volume level. -
Page 14: Rear Ports On The Soundbar
Rear Ports on the Soundbar Play your stored media files (supported file codecs and extensions STORAGE may vary). Use the supplied 3.5mm audio cable to connect the headphone AUX IN SOUND socket of the connected audio device, such as a media player, to the AUX IN socket on the unit. - Page 15 Rear Ports on the Soundbar Before connecting the AC power adaptor cord, ensure you have DC IN completed all other connections. POWER Connect the AC power adaptor cord to the DC IN socket first, then plug in the AC power adaptor to the mains supply socket. HDMI (ARC) To use the ARC function, make sure the soundbar's HDMI (ARC) socket is connected via a HDMI cable (not included)
-
Page 16: Wireless Subwoofer
Wireless Subwoofer PAIR Rear Bottom 1. Power button: Turn subwoofer on/off by flicking the button 2. Power cord: Connect to power 3. Connection indicator (flashes blue when ready to pair, lights up blue when paired) 4. PAIR button: Press and hold to start pairing with the soundbar 5. - Page 17 Pairing the wireless subwoofer with the soundbar after first time use • The subwoofer and soundbar will automatically pair when they are both plugged into the mains sockets and turned on. No cable is needed for connecting the two. • Flick the power button on the subwoofer on and the connection indicator will flash blue, meaning it is currently ready for pairing.
-
Page 18: Wireless Rear Speakers
Wireless Rear Speakers Rear Front 1. Wall mount hole 2. DC IN: connect to power using the supplied 20V, 1.2A AC adaptor 3. PAIR button: Press and hold to start pairing with the soundbar 4. Connection indicator (flashes blue when ready to pair, lights up blue when paired) Pairing the rear speakers with the soundbar for the first time Note: the rear speakers must be manually paired with the soundbar for first time use. - Page 19 Pairing the rear speakers with the soundbar after first time use. • The rear speakers and soundbar will automatically pair when they are both plugged into the mains sockets and turned on. No cable is needed for connecting the two. • Use the supplied 20V, 1.2A AC adaptor to connect to the DC IN port of the rear speaker and the other end of a mains socket to turn on, the connection indicator will flash blue.
-
Page 20: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AAA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 21: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the soundbar. The remote will not operate if its path is blocked. The remote has a range of up to about 6 metres from the soundbar at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 22: Remote Overview
Remote Overview : Switch the soundbar on or SURR+ : Increase volume level of standby rear speakers SURR- : Decrease volume level of : Skip to the next track rear speakers : Start or pause playback : Increase volume level : Press to select movie : Skip to the previous track sound effect... -
Page 23: Operation
Operation General Operation Input Modes Function Action Input Display Tap the button on the soundbar HDMI (when no Turn the soundbar ON HDMI IN 1 or press the button on the remote input signal) control. HDMI IN 2 Hd-1/Hd-2 Tap the button on the soundbar Turn the soundbar OFF or press the... -
Page 24: Bluetooth
® mode automatically. it to search for compatible devices. Select 'BAUHN ADDSB-0122' from the list of found devices. If a mobile phone on which you are playing music Note: Only one playback unit can be connected to receives a call, the music will be interrupted. -
Page 25: Bluetooth ® Playback
Bluetooth Playback ® Function Action Increase the Volume Tap the button on the soundbar or press the button on the remote. Decrease the Volume Tap the button on the soundbar or press the on the remote. Play/Pause Press the button on the remote. Skip/Rewind Press the buttons on the remote to skip/rewind tracks. -
Page 26: Troubleshooting
Troubleshooting If you have problems with the soundbar, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 002 534. Problem Solution • Ensure that the power adaptor is properly connected. No power •... - Page 27 Problem Solution • Make sure the input source is set to ARC; the LED will display 'ARC'. • Make sure your TV or external device supports ARC function and connect the HDMI cable to the ARC port of the TV or external device. •...
- Page 28 Problem Solution • Make sure the LED screen is displaying 'AUX'. Turn up the volume on the soundbar. No sound in AUX IN mode • Turn up the volume on the external device and make sure it’s not paused or muted. •...
-
Page 29: Specifications
1300 002 534 side of sensor) distance, angle tempo.org/support Bluetooth pairing Distributed by Tempo (Aust) Pty Ltd, operation range – Up to 10 metres distance PO Box 132, Frenchs Forest NSW 1640 Bluetooth pairing BAUHN ADDSB-0122 name SPECIFICATIONS | 29... -
Page 30: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging Compliance The packaging of your product has been This product complies with the Australian Safety selected from environmentally friendly Standard AS/NZS 62368.1 to ensure the safety of the materials and can usually be recycled. Please ensure product. -
Page 31: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 32: Repair And Refurbished
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 33 Notes...
- Page 34 Notes...
- Page 35 Notes...
- Page 36 Online support Visit bauhn.com.au for software updates to keep your soundbar up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns tempo.org/support Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
