HDPlex H5 Fanless HTPC Classis Installation Manual page 3

H5 Chassis Body
Top Plate
Left Side Panel
Back Plate*2 (Dual Slot and Low Profile)
H5 Chassis Faceplate
Faceplate (Silver or Black)
H5 Heatsink System
Aluminum Top Plate
Copper Baseplate
Eight 6mm OD Coppper Heatpipes
Installation Screw Kit
H5 Accessories
Multipurpose HDD Rack x 2
Internal USB 3.1 Type C Cable x1
HEX Screw Driver and Allen Wrench
AC Socket Adapter Plate x 1
Installation Screw Kit
Aluminum Power Button w/Cable x 1
Installation Screw List:
A:M3*5mm Round Head Screw with Cushion 12pcs for motherboard installation
B: Hex Socket Cap Head Screws M5*14mm 8pcs For Front and Handle
Installation; M5*8mm 8pcs for Faceplate Front and Back Plate Mounting.
C:M4*8 Flat Head HEX Screw-Black 10pcs For Top Plate/Bottom Plate/Side
Panel Installation
D:M3*5 Flat Head Screw –Black 12pcs For SSD mounting/AC IEC installation
E: 7mm Hexagonal Copper Stud for Motherboard Installation 12pcs
F: 6-32 Thread 6mm Screw- Silver 8pcs For 3.5" HDD Installation
G: Hexagonal Copper Stud for HDD Rack:10mm-8pcs 25mm-8pcs
J: M3 Round Head 8mm Screw 8pcs
Package Contents
Bottom Plate
Right Side Panel
Four Feet with Rubber Cushion
Heatpipe Installation Plate x5
High Quality Thermal Paste 3.5g
Dumbbell Tool to apply thermal paste
Multipurpose CPU Bottom Plate x1
ATX/SFX/FlexPower Supply Rack x 1
Internal AC Extension Cord x 1
DC Socket Adapter Plate x 1
PCI Cover Bracket x 4 (Low Profile x 1)
Internal USB 3.0 Cable x1
Front Handle x 2
