HDPlex H5 Fanless HTPC Classis Installation Manual

Hide thumbs Also See for H5 Fanless HTPC Classis:

Advertisement

Quick Links

Download this manual
H5 Fanless HTPC Chassis
Installation Guide V 3.0
Page 1 of 21

Advertisement

loading
Need help?

Need help?

Do you have a question about the H5 Fanless HTPC Classis and is the answer not in the manual?

Questions and answers

Related Manuals for HDPlex H5 Fanless HTPC Classis

Summary of Contents for HDPlex H5 Fanless HTPC Classis

  • Page 1 H5 Fanless HTPC Chassis Installation Guide V 3.0 Page 1 of 21...
  • Page 2 Paypal/Rü ckerstattung zu Ihrem Auftrag. Offre de remboursement HDPLEX Recevez 30 dollars US pour tout achat d'un boitier HDPLEX. Pour bé né ficier de cette offre, rien de plus simple: prenez deux ou trois photos de votre installation HDPLEX H5 accompagné es de vos commentaires ou suggestions (dans la langue de votre choix) puis postez-les sur un blog, sur Facebook, ou sur n'importe quel forum.
  • Page 3 Package Contents H5 Chassis Body Top Plate Bottom Plate Left Side Panel Right Side Panel Back Plate*2 (Dual Slot and Low Profile) Four Feet with Rubber Cushion H5 Chassis Faceplate Faceplate (Silver or Black) H5 Heatsink System Aluminum Top Plate Heatpipe Installation Plate x5 Copper Baseplate High Quality Thermal Paste 3.5g...
  • Page 4 H5 Chassis Bottom Plate Installation Install four feet with rubber cushion to the bottom plate back side. Install Hexagonal Copper Stud 7mm to the bottom plate, matching your motherboard installation position Install the aluminum power button on the right panel using lock ring from the internal side.
  • Page 5 Install right heatsink panel onto the H5 bottom plate using 2pcs C. When installed correctly, the mounting ear should face forward with power button above the heatpipe groove. H5 CPU Heatsink System Installation CPU Heatsink Installation Kit List: H-1: M3*5mm Flat Head Silver Screw 4pcs H-2: M3*10mm CUP Head HEX Screw Silver 8pcs H-3: M3 Hand Turn Screws 4pcs H-4: M3*14mm Flat Head Screw Black 16pcs...
  • Page 6 H-6: Intel CPU LGA115x/1200 Rack 2pcs H-7: AMD AM4 Rack 2pcs H-8: Plastic Screw Holder Black 4pcs H-9: Aluminum Plate for Heatpipe Installation 4pcs H-10: Aluminum Plate for Heatpipe Installation Half Width 1pcs H-11:M3 Screws for CPU Bottom Rack Installation 4pcs Remove protection cover from the copper base plate and install two H-6 for Intel or H-7 for AMD...
  • Page 7 Install the 4pcs H-11 on to the H-5 CPU bottom rack. Remove the original CPU bottom plate from your motherboard. Install this H11+H5 structure to the back of motherboard, replacing the original motherboard CPU bottom plate`. Intall 4pcs onto the H-11. Apply a thin layer of thermal paste on top of CPU and install copper base using 4pcs H-3.
  • Page 8 Install motherboard onto the H5 bottom plate copper stud using and install heatpipe 1-8. Apply thin layer of thermal paste inside copper base groove and side heatsink panel groove using the dumbbell tool Warning: Do not over apply thermal paste as it will decrease heat transfer efficiency. Page 8 of 21...
  • Page 9 Tighten the to the side panel using which goes through the hole on the side panel from outside of the H5 chassis. square shape and needs to be in the correct direction to match the mounting hole. Usually 3pcs are needed to fully lock the heatpipes on the side panel.If the left side H-9 is too close to the H5 back plate.

  • Page 10: Power Supply Installation

    Power Supply Installation HDPLEX 400W AC-DC+400W DC-ATX NanoATX Combo HDPLEX 400W AC-DC is back mounted on the H5 bottom plate via the M2.5 screws come with the HDPLEX 400W AC-DC package. HDPLEX 400W AC-DC optional mounting ears are NOT used for H5 installation.
  • Page 11 If you are using standard ATX/SFX/FlexPSU inside H5 for ITX or narrow width ATX/microATX motherboard, attach the universal rack to the power supply using 2pcs first. Plug the AC extension cord to the power supply and install them to the PSU rack mounting hole on the top left of the H5 bottom plate using 2pcs D.

  • Page 12: Hard Drive Installation

    Hard Drive Installation Install 3.5” HDD using and 2.5” HDD/SSD using to the hard drive rack. SSD data and power connector will stick out a bit of the HDD rack for SATA cable easy access. Page 12 of 21...
  • Page 13 If you are using HDPLEX 400W NanoATX Combo power supply, we recommend using 2x25mm length copper stud to form 50mm high post install the HDD rack. You could install two SSD and one 3.5” HDD on top of 400W DC-ATX converter and two SSD on top of 400W AC-DC adapter with HDD rack reversed.
  • Page 14 Backplate and PCI-E Card Installation Please install the power adapter plate on to the H5 back plate before install the back plate to the H5 chassis. If you use AC C14 IEC connector, please install the AC adapter plate using 4pcs from the internal side of the backplate and AC C14 connector using 2pcs If you are using 7.4*5.0mm self-lock connector, please install the DC Adapter Plate using 2pcs...
  • Page 15 HDPLEX ATX Modular Bridge Input Board (This product is included in HDPLEX 500W ATX linear PSU). Install 4pcs 4mm copper post (comes with the ATX Modular board) onto the H5 back plate. Install the ATX modular bridge board using 4pcs ATX Modular bridge board will conflict with H5 side heatsink panel if installed incorrectly.
  • Page 16 First, please connect the PCIEx16 riser card to your video card and turn on PC to test. If test fine and PCIEx16 card is showing the correct PCIE version (3.0) and speed (x16) under benchmark or load test, disconnect everything. HDPLEX GPU heatsink system parts list: Eight 6mm OD Copper Heatpipes Aluminum Top Cover Copper Base Plate High Quality Thermal Paste 3.5g...
  • Page 17 Install the video card to the H5 back plate. Slide the dual bracket tip inside and using 1pcs firmly attach the video card bracket to H5 back plate. Apply thin layer of thermal paste to the side panel groove and install eight heatpipes following the below pattern.
  • Page 18 Install the 3pcs aluminum plate on the side panel using first and aluminum top cover using 8pcs Page 18 of 21...

  • Page 19: Faceplate Installation

    Faceplate Installation If you don’t need front handle, just mount the faceplate using 4 HEX Socket Cap Head M5*14mm to the two H5 side heatsink panel. To install optional handle. First use 4pcs Hex Socket Cap Head M5*14mm install the front handle from the back of the faceplate. Use 4pcs Hex Socket Cap Head M5*8mm to mount the faceplate onto side heatsink panel mounting ear from the back.
  • Page 20 Page 20 of 21...
  • Page 21 For suggestions and advice on HDPLEX fanless chassis, please visit our community at https://www.hdplex.com/forum Copyright 2019-2022 HDPLEX LTD. All rights reserved. All trademarks are the property of their respective owners. Reproduction in whole or in part without written permission is prohibited.
