Summary of Contents for Omcan 7 QT MX-CN-0007-HW
- Page 1 Bakery 7 QT Mixers Models MX-CN-0007-HW, 0007-HG Items 44306, 44475 Instruction Manual Revised - 02/14/2022 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model MX-CN-0007-HW / Model MX-CN-0007-HG Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 7 Installation --------------------------------------------------------------------------------------- 7 - 8 Operation ----------------------------------------------------------------------------------------- 8 - 9 Maintenance ----------------------------------------------------------------------------------------- 9 Troubleshooting ------------------------------------------------------------------------------- 9 - 10 Parts Breakdown... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 Do not use an extension cord with this equipment. Do not plug this equipment into a power strip or multi- outlet power cord. • Non-Omcan attachments are not recommended. They will not work properly and will void the warranty. • Check equipment before each use to insure the equipment is clean.
- Page 6 Safety and Warranty • If the power cord is damaged, it must be replaced by an Omcan authorized agent or recommended qualified technician in order to avoid a hazard. • Never use accessories which are not recommended by the manufacturer. They could pose a safety risk to the user and might damage the appliance.
-
Page 7: Technical Specifications
Ensure the appliance is switched off and disconnected from power supply before assembly/disassembly. • Omcan accepts no responsibility for any injury caused by incorrect assembly of this appliance. • The bowl must be attached into position prior to starting the Planetary Mixer. -
Page 8: Installation
Installation 2. Raise the mixer head as instructed previously. 3. Push the mixer attachment up and to the left to release. 4. Insert the desired attachment. Push up and to the right to lock it into place. 5. Lower the mixer head in place. Mixer Attachments Intended Use Suitable Speed... -
Page 9: Maintenance
The unit is not switched on. Check the unit is plugged in correctly and switched on. Plug and lead are damaged. Call Omcan or a qualified Omcan Technician. Fuse in the plug has blown. Replace the fuse. Problem with the power supply. - Page 10 Mixing speed too high or a wrong Select the suitable speed and mixing attachment used. mixing attachment. The appliance is noisy. Bowl or mixing attachment not Remove and refit bowl/mixing correctly fitted. attachment. Bowl or mixing attachment is Call Omcan or a qualified Omcan deformed. Technician.
-
Page 11: Parts Breakdown
Parts Breakdown Model MX-CN-0007-HW 44306 Model MX-CN-0007-HG 44475... - Page 12 Parts Breakdown Model MX-CN-0007-HW 44306 Item Item Item Description Position Description Position Description Position 67126 White Cover for 44306 67153 Circlip for Hole for 44306 67180 Switch Base for 44306 67127 Band for 44306 67154 Screw for 44306 67181 Speed Control for 44306 67128 Screw for 44306 67155...
- Page 13 Parts Breakdown Model MX-CN-0007-HG 44475 Item Item Item Description Position Description Position Description Position AJ386 Gray Cover for 44475 67153 Circlip for Hole for 44475 67180 Switch Base for 44475 67127 Band for 44475 67154 Screw for 44475 67181 Speed Control for 44475 67128 Screw for 44475 67155...
-
Page 14: Electrical Schematics
Electrical Schematics Model MX-CN-0007-HW 44306 Model MX-CN-0007-HG 44475... -
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
