MP211 GENERAL INFORMATION

1.1 Physical Interfaces

1
Digital Input GND Connection
2
Analog Output Connections
3
Analog GND Connection
4
Analog Input Connection
5
RS485 Connections
6
RS-232 GND Connections
7
Rs232 TX-RX Connections
8
None
9
None
10
Relay Connections
11
CANBUS Connection
12
Digital Input Connections
13
Digital Output Connections
14
Digital Output Supply(Vin) Connection
15
Digital Output GND Connection
16
Device Power (V+) Connection
17
Device Power (V-) Connection
18
Ethernet Port
6
Figure 1 Connector and Physical Interfaces
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
USB Port
Relay Status Information LED
Digital Output Status Information LED
Digital Input Status Information LED
System Power LED
System Running LED
Error LED
Protocol Data Transfer LED
Antenna Connection
SIM Card Slot
SD Card Slot
LCD Screen
LCD Screen Back Button
LCD Screen Up Button
LCD Screen Input Button
LCD Screen Forward Button
LCD Screen Down Button
