Interactive Counterbalance Flat Screen
Desk Mount Instruction Manual
V2.0
Model: HADSK5
Thank you for choosing this product! We strive to provide you with the
best quality products and services in the industry. Should you have any
issues, please don't hesitate to contact us at
supportus@huanuoav.com (US/CA/DE/UK/FR/IT/ES/AU)
Advertisement
Related Manuals for HUANUO HADSK5
Summary of Contents for HUANUO HADSK5
- Page 1 Interactive Counterbalance Flat Screen Desk Mount Instruction Manual V2.0 Model: HADSK5 Thank you for choosing this product! We strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at...
-
Page 2: Weight Restrictions
IMPORTANT SAFETY INFORMATION Please carefully read all instructions before attempting installation. If you do not understand the instructions or have any concerns or questions, please contact our customer service at supportus@huanuoav.com. CAUTION: Avoid potential personal injuries and property damage! • Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. -
Page 3: Product Features
Product Features 270° C-Clamp Mounting Grommet Mounting... - Page 4 TENSION ADJUSTMENT SHOULD BE DONE ONLY AFTER MOUNT INSTALLATION Do not adjust tension without monitor. 1. Ensure monitor has been attached to the mount. 2. Read your monitor box or manual to find out monitor net weight. 3. Ensure the net weight of monitor (including accessories) is within 17.6 Ibs (8 kg).
- Page 5 Supplied Parts and Hardware List Bolt Bolt Connecting Desk Clamp Arm Assembly M6x10mm M6x12mm Plate Grommet Monitor Plate Bolt Bottom Butterfly Nut Bolt Allen Key Plate Plate Allen Key Bolt Bolt Washer M4x12mm (x4) M6x12mm (x4) D6 (x4) Step 1A For Clamp Mounting Connect Connecting Plate [B] to Arm Assembly [A] 1A-1...
- Page 6 Secure Desk Clamp [C] to Connecting Plate [B] According to the 1A-2 Thickness of the Desktop 10-50mm 50-83mm (0.4in.-2in.) (2in.-3.3in.) 1A-3 Secure the Mount to Desktop Step 1B For Grommet Mounting 1B-1 Secure Bottom Plate [F] and Bolt [H] to Arm Assembly [A]...
- Page 7 1B-2 Secure the Mount Assembly to the Desktop 0.4-3.3 in. (10-83 mm) Select Monitor Bolts Only one bolt size fits your monitor. Bolt length: Verify adequate thread engagement with bolts or bolts/spacers combination. We recommend thread engagement by at least 5 turns. -Too short will not hold the monitor.
- Page 8 Step 3 Secure the Monitors to Arm Assembly The tension is preset at 4-5kg. After hanging the monitor to the mount, please release the monitor slowly to prevent it from falling suddenly Step 4 Adjust the Gas Spring Tension Be sure to keep the arm in horizontal position during adjustment.
- Page 9 Step 5 Adjustments Tilt Adjustment “+” Clockwise: Tighten “-” Counter-clockwise: Loosen Situation 1: If the monitor can stay at the desired tilt angle by itself, no adjustment needed. Situation 2: If the monitor can not stay at the desired tilt angle by itself, turn the bolt clockwise or counter-clockwise as shown until the monitor can stay at the desired tilt angle by itself.
- Page 10 Step 6 Route the Cables Along the Arm Assembly [A] Step 5-1 Detach the cable covers from the arm assembly [A] Note: Loosen the preassembled bolts from the covers, then pinch the both sides of the bottom end of the cable covers to make them detach from the arm Step 5-2 Route the cables along the arm assembly and secure the cable covers to the arm assembly [A]...
- Page 12 Thank you again choosing this product! All of us do appreciate your product purchase. We hope that you are as happy with your product as we are designing and manufacturing it for you. We strive to provide you with the best quality products and services in the industry.
