Mid America Motorworks 648-740 Instruction Sheet

Application: 2006-2013 Corvette
Quick Release Front Plate Frame Z06/GS
Tools Needed
INSTALLATION:
STEP 1.
Jack up car and place on jack stands in such a manner to gain easy access to the bottom of the front bumper. Refer to
user's manual for correct jacking procedure.
STEP 2.
With the 7mm socket and nut driver handle remove and save the 7mm screws that hold the lower air dam to the fascia
at the three slots on the left (driver's) side of the car. Remove the 7mm screws on either side of the driver's side skid
plate at the back of the fascia and pull the fascia down slightly to gain access to the top of the skid plate.
STEP 3.
Using the 7mm screws mount the forward portion of the mounting bracket to the fascia behind the air dam but do not
tighten the screws as you will need to adjust the mount left or right to get proper alignment.
STEP 4.
Push the bracket up against the skid plate and insert the machine screw through the two slotted holes in the mount.
Install the wing nut and hand tighten.
STEP 5.
Replace the rear section of the fascia and install screws and tighten.
STEP 6.
Insert frame through the lower air dam holes and into the mount bracket until it snaps in place. Noting where the
alignment of the plate frame through the holes is equidistant from each side of the air dam holes, pull out the plate
frame and tighten the front 7mm screws.
STEP 7.
Lower car off jack stands. Insert your license plate into the plate frame and install the ¼" 20 X 5/8" screws into the
lower two holes in the plate frame. Installation is now complete.
USE:
The plate frame is easily removable when appropriate, such as for car shows, photo shoots, and racing. Simply pull on
the frame in a straight and forward motion and it will pop loose. To replace the plate frame into the mount receiver,
push the plate completely into the mount bracket until both pins are completely engaged. Verify this either by feel or
visually. Verification is important to prevent inadvertent loss of the plate frame.
Mamotorworks
@CorvettePassion
MidAmericaMotorworks
CorvettePassion
2900 Nor th Third Street, Ef fingham, IL 62401
800.500.1500 • Worldwide: 217.540.4200 • FAX: 217.540.4800
w w w.mamotor work s.com • generalmail@mamotor work s.com
©Mid America Motorworks, Inc. All rights reserved.
INSTRUCTION SHEET
Part Number
648-740
Part Includes
1 - Mounting Bracket
1 - Removable Plate Frame
1 - Hardware Kit
Exterior Body Trim
