Mid America Motorworks 612-607 Instruction Sheet

Application: 1968-1969 Corvette
Shifter Console
Tools Needed

BEFORE INSTALLING

Inspect the Shifter Console Housing you have received to verify it is the correct year and color before starting your installation. The
year range of the console can be determined as follows:
STEP 1.
1968-1969 consoles do not have stitching along the top corners of the console. There is also a cut-out for fiber optics in front of the
main opening.
STEP 2.
1970 consoles have stitching but do not have two small "ears" at the top front corners where the console meets the small gauge
bezel. There is also a cut-out for fiber optics in front of the main opening.
STEP 3.
1971 consoles have stitching and have the two small "ears" at the top front corner where the console meets the small gauge bezel.
There is also a cut-out for fiber optics in front of the main opening.
STEP 4.
1972-1976 consoles have stitching and the "ears" but do not have the cut-out for fiber optics.

REMOVE EXISTING CONSOLE

STEP 1.
Remove the two Phillips screws on each side of the park brake console.
STEP 2.
Locate and remove the bolt in the middle rear of the park brake console. This bolt goes through the fiberglass panel behind the seat
and into a bracket on the park brake consol. To gain access to this bolt, open the rear compartment door on the passenger side and
remove the tray. Reach through the opening toward the center of the car and remove the bolt with a 3/8" wrench or socket.
STEP 3.
Lift the rear of the park brake console, slide it over the emergency brake handle and remove it from the car.
STEP 4.
Set the parking brake.
Mamotorworks
@CorvettePassion
MidAmericaMotorworks
CorvettePassion
2900 Nor th Third Street, Ef fingham, IL 62401
800.500.1500 • Worldwide: 217.540.4200 • FAX: 217.540.4800
w w w.mamotor work s.com • generalmail@mamotor work s.com
©Mid America Motorworks, Inc. All rights reserved.
INSTRUCTION SHEET
Part Number
612-607
Part Includes
1 - Component
Foward Shifter Consoles
