Erskine Attachments 54 Operator's Manual

Hide thumbs Also See for 54:

Operator's manual (20 pages)

Table Of Contents

Quick Links

Utility Snowblower

54" – 60" – 72" – 84" Models

Rear Mounted – CAT. I

3-Point Snowblower

For

Compact Tractors

Operator's Manual

Set-Up Assembly

Maintenance

Parts Information

Read this Manual Before Use

Table of Contents

Need help?

Do you have a question about the 54 and is the answer not in the manual?

Questions and answers

Summary of Contents for Erskine Attachments 54

Page 1 Utility Snowblower 54” – 60” – 72” – 84” Models Rear Mounted – CAT. I 3-Point Snowblower Compact Tractors Operator’s Manual Set-Up Assembly Maintenance Parts Information Read this Manual Before Use...
Page 2: Table Of Contents
Serial Number………….._____________ YOUR ATTACHMENTS DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold.
Page 3: Safety
Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury. hazard. The safety messages found in this manual ...
Page 4  penetrate the skin causing serious Do not modify equipment or add attachments that injury. are not approved by Erskine Attachments LLC.   Avoid the hazard by relieving the Use adequate safety warning lights and devices as required by local regulations. Obey all local laws...
Page 5 SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation.
Page 6 SERIAL NUMBER AND SAFETY DECAL LOCATIONS________ Safety Decals Locations: The locations of the safety decals are shown. If these decals are missing, damaged, or painted over they must be replaced. Call Erskine Attachments LLC (218-435-4045) for replacement decals. Part number: 102935 Part number: 102946...
Page 7: Set-Up Assembly
SET-UP ASSEMBLY Manual Rotation Discharge Chute Installation 1. Bolt the hand crank support bracket to the upper arm, and insert the crank tube. Bolt the lower end of the crank tube to the spool. The crank handle length is adjustable. Start with the crank in the shortest position until the snowblower is mounted to the tractor for the first time.
Page 8 SET-UP ASSEMBLY 9. Turn the crank handle clockwise to wind up the cable on the lower part of the spool. Keep tension on the loose end of the cable while cranking so that the cable on the spool doesn’t unwind. Stop cranking when the chute faces the front left corner of the snowblower body.
Page 9 SET-UP ASSEMBLY Hydraulic Rotation Discharge Chute Installation 1. Remove one of the roller guides from the snowblower housing by removing the bolt securing the roller guide. 2. Remove the chain cover from the snowblower housing by removing the two bolts securing the cover.
Page 10 SET-UP ASSEMBLY Mounting and Adjusting the Snowblower 1. Install the splined yoke of the driveline on the snowblower gearbox shaft. This end of the driveline is secured with a sliding lock collar like the tractor end. Pull back on the collar and push the yoke onto the gearbox shaft.
Page 11 SET-UP ASSEMBLY 5. After the snowblower backward tilt is determined and set, the driveline telescoping length must be checked. 6. With the snowblower resting on the ground, connect the driveline to the tractor PTO shaft and mark the location of overlap on the driveline. Check to make sure that there is sufficient clearance between the driveline and the tractor drawbar.
Page 12 SET-UP ASSEMBLY 11. With the operator in the seat of the tractor and the seat belt fastened, start the engine. With the engine at an idle, check that the hydraulic functions are working properly by rotating the chute all the way in both directions. 12.
Page 13: Mounting Instructions
PTO drive is engaged. IMPORTANT: Maximum driveline extension is 9” for the 54” and 60” models, and 17” for the 72” and 84” models. This allows for a minimum overlap of 5”. Extending beyond these lengths could allow the driveline to separate and lead to equipment damage.
Page 14 MOUNTING INSTRUCTIONS 4. If the snowblower is equipped with the hydraulic chute rotation option, connect the snowblower chute rotation hoses to the tractor’s remote hydraulic couplers (see the tractor’s operator’s manual for remote hydraulic coupler locations and connection instructions). Make sure hoses are routed so that they will not catch on any part of the tractor or snowblower or contact any moving parts during operation.
Page 15: Operating Instructions
OPERATING INSTRUCTIONS Know your work area. Avoid obstructions and debris. 1. Before starting the tractor engine, check to see that the snowblower is nearly level to the ground. This creates a straighter driveline angle and can be accomplished by adjusting the length of the tractor’s 3-point top link (refer to the tractor’s operator’s manual for top link adjustment instructions).
Page 16 OPERATING INSTRUCTIONS 4. With the operator in the operator’s position, check 9. Increase the tractor engine speed to full throttle. to be sure all operating controls are in neutral and Always operate the snowblower with the engine at start the engine. full throttle for maximum efficiency.
Page 17 _____________________ROUTINE MAINTENANCE________________ Lower the attachment to rest flat on the ground, disengage the PTO drive, shut down the engine, relieve hydraulic pressure to the attachment, set the park brake, and wait for all motion to stop before leaving the operator’s position or approaching the attachment to perform service of any kind. It is the operator’s responsibility to make daily inspections of the tractor and attachment for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem.
Page 18: Routine Maintenance
ROUTINE MAINTENANCE Grease the three chute roller guides every 40 hours of operation. Use clean engine oil or roller chain lubricant to lubricate the chute rotator chain (if equipped) every 40 hours of operation. Grease the bearings on each end of the auger every 80 hours of operation.
Page 19 ROUTINE MAINTENANCE Gearbox Oil Level Check and Fill Check the auger drive gearbox oil level monthly. To check the oil level, remove the set screw dipstick from the top of the gearbox and inspect for proper oil level. If low, add SAE 80W-90 gear oil and recheck with dipstick.
Page 20 ROUTINE MAINTENANCE Discharge Chute Adjustment (Manual Rotation) 1. Rotate the chute all the way to the side needing adjustment. 2. Loosen the set screw holding the cable in place. 3. Using pliers, pull the cable through the hole until the cable is tight. 4.
Page 21: Bolt Torque Information
BOLT TORQUE INFORMATION...
Page 22: Parts Information
3/8 X 3/8 37210 NUT REV LOCK 1/4 NC 36314 NUT HEX FULL 5/8 NC (5) 54", (6) 60", (7) 72", (8) 84" 33630 WASHER LOCK 5/8 (5) 54", (6) 60", (7) 72", (8) 84" 300498 CUTTING EDGE B 56 DB...
Page 23 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 13214 BOLT HEX 1/2 X 2‐3/4 NC GR 5 ELEC. DEFLECTOR PKG 13114 BOLT HEX 3/8 X 2 3/4 NC GR5 ELEC. DEFLECTOR PKG 310574 DEFLECTOR LINKAGE BRKT W/A ELEC. DEFLECTOR PKG 13213 BOLT HEX 1/2 X 2‐1/2 NC GR 5...
Page 24 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 420259 AUGER 14D X 54 W/A L20 X 54 420260 AUGER 14D X 60 W/A L20 X 60 420261 AUGER 14D X 72 W/A L24 X 72 420262 AUGER 14D X 84 W/A...
Page 25 PARTS INFORMATION...
Page 26 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 320243 REPAIR KIT U‐JOINT 14S USED IN DRIVELINE 420286 320385 REPAIR KIT U‐JOINT 35S USED IN DRIVELINE 420285 320241 YOKE ASSM BALL SHEAR 14S USED IN DRIVELINE 420286 320371 YOKE ASSM BALL SHEAR 35S 540 USED IN DRIVELINE 420285 420291 YOKE 14S SLIDE LK 1 3/8 21 T SPL...
Page 27 PARTS INFORMATION...
Page 28 L24 X 72 315878 BRACKET URETHANE 81 W/A L24 X 84 315884 CUTTING EDGE URETHANE 51 L20 X 54 URETHANE PKG 315459 CUTTING EDGE URETHANE 57 L20 X 60 URETHANE PKG 315460 CUTTING EDGE URETHANE 69 L24 X 72 URETHANE PKG...
Page 29 PARTS INFORMATION...
Page 30: General Specifications
GENERAL SPECIFICATIONS 54” 60” 72” 84” Model Stage 54” 60” 72” 84” Working Width 56” 62” 74” 86” Overall Width 42” 42” 42” 42” Overall Length 63” 63” 67” 67” Overall Height 24” 24” 28” 28” Cutting Height 20” 4-blade 20”...
Page 31 Erskine Attachments LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold.
Page 32 P/N 420290 Date Printed: 1/15/2019 Printed in U.S.A. Erskine Attachments LLC...

This manual is also suitable for:

60 72 84
