  6. Operator's manual

Erskine Attachments 68 Operator's Manual

Angle broom for skid steer loaders
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Angle Broom
For
Skid Steer Loaders
Operator's Manual
Set-Up Assembly
Maintenance
Parts Information
Read this Manual Before Use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 68 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Erskine Attachments 68

Summary of Contents for Erskine Attachments 68

  • Page 1 Angle Broom Skid Steer Loaders Operator’s Manual Set-Up Assembly Maintenance Parts Information Read this Manual Before Use...

  • Page 2: Table Of Contents

    Serial Number………….._____________ YOUR ATTACHMENT DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold.

  • Page 3: Safety

    Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury. hazard. The safety messages found in this manual ...
  • Page 4  Do not modify equipment or add attachments that PARTS, to check for suspected leaks. Wear are not approved by Erskine Attachments LLC. protective gloves and safety glasses or goggles when servicing or performing maintenance on  Use adequate safety warning lights and devices as hydraulic systems.

  • Page 5: Serial Number/Decal Location

    SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation.
  • Page 6 The locations of the safety decals are shown. If these decals are missing, damaged, or painted over Location: On each endplate (Small) they must be replaced. Call Erskine Attachments Quantity: 1 (Large) LLC (218-435-4045) for replacement decals. Quantity: 2 (Small)

  • Page 7: User's Mounting Instructions

    USER’S MOUNTING INSTRUCTIONS After the initial set-up assembly is completed use the following procedure to mount the attachment to the loader for user operation. Coupler wedges or pins must extend through the holes in the attachment. Levers must be fully down and locked. Failure to secure wedges or pins can allow the attachment to come off and cause injury or death.
  • Page 8 USER’S MOUNTING INSTRUCTIONS 7. Connect the hydraulic quick couplers from the attachment to the loader. IMPORTANT: Wipe the ends of the hydraulic quick couplers (both lead and loader) with a rag remove possible contamination. Contamination can cause hydraulic components to fail and is not covered under warranty. IMPORTANT: Make sure the quick couplers are fully engaged.

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS IMPORTANT: Before operation, make sure the Parking Stand parking stands have been secured in the operating position. 1. With the operator in the seat of the loader, the seatbelt fastened, and the seat bar lowered (if so equipped), start the engine. 2.
  • Page 10 OPERATING INSTRUCTIONS Manual Angling of the Attachment Avoid manually adjusting the broom angle while parked on sloped surfaces. Removing the angle pin while parked on sloped surfaces can cause the broom to move on its own due to gravity. If it is necessary to adjust the angle on a sloped surface, approach the angle pin from the uphill side.

  • Page 11: Routine Maintenance

    ROUTINE MAINTENANCE Lower the attachment to rest on the parking stands, shut down the engine, relieve the hydraulic pressure to the attachment, set the park brake, and wait for all motion to stop before leaving the operator’s seat to perform service of any kind. It is the operator’s responsibility to make daily inspections of the loader and attachment for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem.
  • Page 12 ROUTINE MAINTENANCE Replacing Brush Sections 1. Use the snapper pins to lock both parking stands in the parking position. 2. Lower the attachment to rest on the parking stands. 3. Remove the four bearing mount bolts and nuts. 4. Remove the four motor mount bolts and nuts. 5.
  • Page 13 ROUTINE MAINTENANCE 8. Number the ribs on the arbor as 1, 2, and 3. 9. Slide the first “wavy” brush section on so that the pins are around rib 1. 10. Slide the second “wavy” brush section on so that the pins are around rib 2.

  • Page 14: Set-Up Assembly

    SET-UP ASSEMBLY Set-Up from Shipping 1. Remove the straps holding the attachment to the pallet. 2. Remove the six bolts and nuts attached to the torsion frame. 3. Position the torsion frame so that the holes are aligned with the holes in the sides of the pivot frame.
  • Page 15 SET-UP ASSEMBLY Wire Harness Installation NOTE: If the loader is equipped with an attachment control package, the appropriate harness should be installed from the factory. If the attachment was ordered with the pistol grip Hose Clamp control harness, follow these instructions: 1.
  • Page 16 SET-UP ASSEMBLY 7. Connect the red fused wire to the positive battery terminal or to a suitable accessory wire with a minimum rating of 5 amps. Route the wiring along the loader main frame toward the front of the loader. Connect the black wire from the harness to a frame ground.
  • Page 17 WIRE HARNESS PARTS INFORMATION REF. PART NO. DESCRIPTION QTY. COMPLETE HARNESS – generic (shown) 315128 …………………………………... PISTOL GRIP – handle assembly w/ harness ……………………………….. 315110 LOADER HARNESS – assembly ……………………………………………… 315126 RECEPTACLE BRACKET – loader harness 202489 …………………………………. ATTACHMENT HARNESS – assembly ………………………………………. 315127 Optional Harnesses (not shown) PART NO.

  • Page 18: Parts Information

    NUT REV LOCK 1/2 NC 21801 BOLT CARRIAGE 1/4 X 3/4 NC GR 5 BOLT FLG THRD RLNG 3/8 X 3/4 NC GR5 ** (6) 68" (8) 84" (8) 96” 32467 316055 CLAMP TUBELINE 5/8 316094 CLAMP TUBELINE TOP PLATE 5/8...
  • Page 19 PARTS INFORMATION...
  • Page 20 WAFER AB CONV POLY/STEEL 32 OBSOLETE NO LONGER USED 316042 WAFER AB CONV POLY 32 (35) 68" (44) 84" (50) 96” WAFER AB CONV POLY 32 (IN POLY/STEEL PKG) (18) 68” (22) 84” (25) 96” 316042 316072 WAFER AB SPACER OBSOLETE NO LONGER USED...
  • Page 21 PARTS INFORMATION...
  • Page 22 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 103396 MOTOR HYD 24 CID 2K STD 316062 TUBELINE ANGLE BROOM 68 316053 TUBELINE ANGLE BROOM 84 316125 TUBELINE ANGLE BROOM 96 REPLACED 201228 330921 CYLINDER 2 X 8 WELDED C-C 201228 CYLINDER 2 X 8 20.25 C-C...
  • Page 23 PARTS INFORMATION Manual Angling Hose Diagram Hydraulic Angling Hose Diagram (Cylinder Hoses) Hydraulic Angling Hose Diagram (Lead Hoses)

  • Page 24: General Specifications

    GENERAL SPECIFICATIONS Model Working Width – Straight 68” 84” 96” Working Width – Fully Angled 63” @ 25° 77” @ 25° 89” @ 25° Broom Angling 25° manual / opt. hyd. Drive System Hyd. motor direct drive 10 – 20 GPM Flow Range 32”...

  • Page 25: Bolt Torque Information

    BOLT TORQUE INFORMATION...

  • Page 26: Notes

    NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...

  • Page 27: Warranty

    Erskine Attachments LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold.
  • Page 28 P/N 320090 Date Printed: 6/8/2018 Printed in U.S.A. Erskine Attachments LLC...
