AVENTOS HF
Wood / wide aluminum door application
Lift mechanism set
Cover plate set
Telescopic arm set
Wood or wide alum door hardware set
CLIP top 120° hinge (qty 2)
■
COMPACT 33° hinge (qty 2)
■
CLIP top bottom door hinge (qty 2)
■
COMPACT mounting plate (qty 2)
■
Face frame adapter (qty 4)
■
Telescopic arm mounting plate (qty 2)
■
NOTE:
Three hinges and mounting plates required
for cabinet widths over 1219 (48")
Hardware set
Inst. screw for wood doors
Inst. screw for wide alum doors
Subject to technical modifications
without notice. © 2010
Lift mechanism (qty 2)
■
#7 x 35 mm (1-3/8") wood screw (qty 10)
■
Power factor
85
— 230 (1 lift mechanism req.)
231
— 470
471
— 880
780 — 1440
1401 — 2300 (3 lift mechanisms req.)
Right and left cover plate
■
Non-handed cover cap (qty 2)
■
Cover plate set
Telescopic arm (qty 2)
■
Cabinet heights
479 (18-7/8")
— 558 (22")
558 (22")
— 686 (27")
686 (27")
— 889 (35")
889 (35")
— 1067 (42")
Mounting plate with bracket set
■
■
Mounting plate w/ bracket set
78Z5530TA5
Inst. screw for wood doors
606N or 606P
Inst. screw for wide alum doors
7072A
1
Left and right mounting plate with bracket
For large overlay five-piece doors
Part no.
20F2200.N5
20F2200.N5
20F2500.N5
20F2800.N5
20F2800.N5
Part no.
20F8000.NA
Part no.
20F3200
20F3500
20F3800
20F3900
Part no.
175H5F00.01
606N or 606P
7072A

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVENTOS HF and is the answer not in the manual?

Questions and answers

Related Manuals for BLUM AVENTOS HF

Summary of Contents for BLUM AVENTOS HF

  • Page 1 AVENTOS HF Wood / wide aluminum door application Lift mechanism set Lift mechanism (qty 2) ■ #7 x 35 mm (1-3/8”) wood screw (qty 10) ■ Power factor Part no. — 230 (1 lift mechanism req.) 20F2200.N5 — 470 20F2200.N5 —...
  • Page 2 TDH x .6 - 57 + TR 272 to 531 TR = Top reveal TDH = Top ddor height Use the Universal individual template to pre-bore the 5 mm locating pin holes for the AVENTOS HF lift mechanism. Part no. 65.1051.01...
  • Page 3 Attaching the lift mechanism Align the lift mechanism in the cabinet using the 5 mm locator pins and attach the mechanism with the five wood screws provided. min 5 #7 x 35 mm (1-3/8") wood screws (qty 5) Attach the telescopic arms WARNING: Risk of injury from spring loaded arm.
  • Page 4 Assembly Small overlay top door hinge planning CLIP top hinges Overlay Overlay table B Bore distance * Bore at 3 then adjust 1 Part no. CLIP top hinge 70T5580 Mounting plate 175H6000 Large overlay top door hinge planning COMPACT hinges Overlay table 1-1/4”...
  • Page 5 Bottom door hinge planning Reveal table B Bore distance 12.7 Part no. CLIP top hinge 78Z5530T Mounting plate 175H6000 Attaching the telescopic arm mounting plates Top door height (TDH) 231 to 271 TDH x .5 + 68 272 to 531 TDH x .5 + 45 NOTE: For five-piece door mounting...
  • Page 6 Assembly Attaching the telescopic arm mounting plate with bracket for five-piece doors Standard mounting plate works ü 12.5 more than 6 Standard mounting plate does not work 12.5 less than 6 ü Use mounting plate with bracket when 12.5 panel is < 6 mm from screw Part no.
  • Page 7 Attach the top door to the cabinet Attach the bottom door Attach bottom door to the top door and attach the telescopic arms Subject to technical modifications without notice. © 2010...
  • Page 8 Assembly Adjust tension of the mechanism Close and flush doors to cabinet. Open and close door to test closing force. Use a screw gun and a #2x2 POZI driver bit to adjust the lift mechanism to the desired tension. Test door again and repeat until desired function is achieved.
  • Page 9 Adjust and lock telescopic arms Open door enough to lock levers 1. Close and flush doors to cabinet. While pressing on 2. Slightly open door and lock the telescopic arms the top door, pull the bottom door open one inch. into position using the levers as shown.
  • Page 10 Removal WARNING Risk of injury from spring-loaded arm Do not push lever arm down or leave in the down position Remove mechanism before installing or removing cabinet Remove covers Detaching the telescopic arms Warning: Risk of injury from spring-loaded telescopic arm! Maintain control of telescopic arm while releasing the CLIP mechanism.
  • Page 11 Removing the doors 1. Hold the bottom door while unclipping the bottom hinges. 2. Hold the top door while detaching the top hinges. Simply unclip them if using the CLIP top hinges or loosen them if using COMPACT. Removing the telescopic arms Using a screwdriver, depress the release tabs to remove telescopic arms.
