X-Rack Owner's Manual
K.3.4 Controls
This is a four band equaliser that can be switched between two different sets of curves; one based on SSL's
'02' ('Brown Knob') EQ and the other based on the latest version of the classic '242' E Series ('Black Knob')
EQ.
HF Band controls:
Frequency
Gain
'Q' (on 'BELL' setting)
HMF Band controls:
Frequency
Gain
'Q'
LMF Band controls:
Frequency
Gain
'Q'
LF Band controls:
Frequency
Gain
'Q' (on 'BELL' setting)
Page K-4
Variable from 1.5kHz to 16kHz
Variable between ±15dB ('Brown')
Variable between ±18dB ('Black')
0.8 ('Brown')
1.3 ('Black')
Variable from 600Hz to 7kHz
Variable between ±15dB ('Brown')
Variable between ±18dB ('Black')
Variable from 0.5 to 2.5 ('Brown')
Variable from 0.5 to 4 ('Black')
Variable from 200Hz to 2.5kHz
Variable between ±15dB ('Brown')
Variable between ±18dB ('Black')
Variable from 0.5 to 2.5 ('Brown')
Variable from 0.5 to 4 ('Black')
Variable from 30Hz to 450Hz
Variable between ±15dB ('Brown')
Variable between ±18dB ('Black')
0.8 ('Brown')
1.3 ('Black')
