Bose ControlSpace ESP-88 Service Manual page 62

Reference
Designator
M100 QUAD 2-INPUT AND, TSSOP14
M101 CMOS, SRAM, TSOP44
M102 MCU, FLASH, UNPROG, FP-100B
M200 HEX INVERTER, TSSOP14
M201 EEPROM, DIP8, ATMEL
M202 ETHERNET CONT, PQFP-100
M300 LED DISPLAY DRIVER, QSOP16
M400 DECODER, TSSOP16
M401 OCTAL BUFFER DRIVER, TSSOP20
M402 OCTAL BUFFER DRIVER, TSSOP20
M403 OCTAL D-TYPE F-F, TSSOP20
M404 IDENTITY COMP, TSSOP20
M500 DC/DC CONVERTER, DIP-24
M501 VOLTAGE DETECTOR, TSOP-5
M501 VOLTAGE DETECTOR, SOT-23-5
M503 OCTAL BUFFER DRIVER, TSSOP20
M504 OCTAL D-TYPE FLIP-FLIP,
TSSOP20
Reference
Designator
CN100 CONNECTOR, 6POLE, P2.5MM
CN200 MODULAR JACK, 7006-8P8C-M-01
CN501 WIRE TO BOARD HEADER,
P5.08MM, 2POLE, 2EHDVC-02P
CN503 PCB SOCKET, DUAL ROW,
P2.54MM, 16POLE, H=7.1MM
E400 ENCODER, SW, 5P, 5V/10mA
E401 ENCODER, SW, 5P, 5V/10mA
E402 ENCODER, SW, 5P, 5V/10mA
E403 ENCODER, SW, 5P, 5V/10mA
E404 ENCODER, SW, 5P, 5V/10mA
JP500 HEADER, P2.54MM, 3PIN, H=6.0MM
JP501 HEADER, P2.54MM, 3PIN, H=6.0MM
LCM HEADER, P2.54MM, 16PIN,
H=6.0MM
SW400 TACT SW, SMT, 12V/50mA, 160g,
SW401 H=5MM, TD-06XA
SW402
SW403
XTAL100 20.000MHz +/-30ppm, 20pF, HC-49/S
XTAL200 20.000MHz +/-30ppm, 20pF, HC-49/S
/JP500 JUMPER, CAP, 2 PIN, 6MM
/JP501 JUMPER, CAP, 2 PIN, 6MM
/LED PCB FLAT CABLE, 18P, 2651, #26AWG,
L=39MM, GREY, UL&CSA
ELECTRICAL PART LIST
CC-64 Control Center
Integrated Circuits
Description
Miscellaneous
Description
62
Vendor Vendor Part
Number
Name
MC74VHC08DT
ON Semi
Samsung K6R1016C1D-TC10
HD64F3069RF25
Hitachi
MC74VHC04DT
ON Semi
ATMEL AT93C46-10PI-2.7
RTL8019AS
Realtek
MAXIM MAX6951CEE
ONSEMI MC74VHC138DT
ON Semi MC74VHC541DT
MC74VHC541DT
ON Semi
ON Semi MC74VHC574DT
74ACT521MTC
Fairchild
EC5A-12S05
Cincon Elec
ONSemi NCP303LSN47T1
Seiko S80947CNMC-G9H-
T2
ON Semi MC74VHC541DT
ON Semi MC74VHC574DT
Vendor Vendor Part
Number
Name
Neltron 2317SJ-06
Neltron 7006-8P8C-M-01
2EHDVC-02P
Dinkle
Neltron 2214S-16G
EC11E15244EF
ALPS
ALPS EC11E15244EF
EC11E15244EF
ALPS
ALPS EC11E15244EF
ALPS EC11E15244EF
2211S-03G
Neltron
Neltron 2211S-03G
Neltron 2213S-16G
Wealth TD-06XAX
Metal
AS-20.000-20
Raltron
Raltron AS-20.000-20
22Z02-0611
Computime
Computime 22Z02-0611
Computime 3618BA00396K0Z04
