Linking And Unlinking Trays - Lexmark X548 Quick Reference

the manual feeder. Load envelopes on the left side of the feeder
with the flap side up.
Note: Align the long edge of the sheet so that it is flush with the
right side of the manual feeder.
3 Adjust the width guides until they lightly touch the sheet. Do not
force the width guides against the sheet. Doing so may damage the
sheet.
4
Push the sheet in until it stops. The printer pulls it in farther.
Note: To achieve the best possible print quality, use only
high‑quality media designed for laser printers.

Linking and unlinking trays

Linking and unlinking trays
1
Open a Web browser, and then type the printer IP address in the
address field.
Notes:
•
View the printer IP address on the printer home screen. The
IP address appears as four sets of numbers separated by
periods, such as 123.123.123.123.
•
If you are using a proxy server, then temporarily disable it to
load the Web page correctly.
2
Click Settings > Paper Menu.
3
Change the paper size and type settings for the trays you are linking.
• To link trays, make sure the paper size and type for the tray
match that of the other tray.
• To unlink trays, make sure the paper size or type for the tray
does not match that of the other tray.
4
Click Submit.
Note: You can also change the paper size and type settings using the
printer control panel. For more information, see
size and type" on page 5.
Warning—Potential Damage: Paper loaded in the tray should match
the paper type name assigned in the printer. The temperature of the
fuser varies according to the specified paper type. Printing issues
may occur if settings are not properly configured.
Creating a custom name for a paper type
If the printer is on a network, you can use the Embedded Web Server
to define a name other than Custom Type [x] for each of the custom
paper types loaded into the printer.
1
Type the printer IP address into the address field of your Web
browser.
Note: If you do not know the IP address of the printer, then you
can:
•
View the IP address on the printer control panel in the TCP/IP
section under the Networks/Ports menu.
8
•
Print a network setup page or the menu settings pages and
locate the IP address in the TCP/IP section.
2
Click Settings > Paper Menu > Custom Name > type a name >
Submit.
Note: This custom name will replace the Custom Type [x] name
under the Custom Types and Paper Size and Type menus.
3 Click Custom Types > select a paper type > Submit.
Assigning a custom paper type name
Assign a custom paper type name to a tray when linking or unlinking
trays.
From the home screen, navigate to:
> Paper Menu > Paper Size/Type > select a custom paper type
name > select a tray > Submit
Configuring a custom name
If the printer is on a network, then you can use the Embedded Web
Server to define a name other than Custom Type [x] for each of the
custom paper types loaded into the printer.
1
Type the printer IP address in the address field of your Web
browser.
Note: If you do not know the IP address of the printer, then you
can:
"Setting the paper
• View the IP address on the printer control panel in the TCP/IP
section under the Networks/Ports menu.
•
Print a network setup page or the menu settings pages and
locate the IP address in the TCP/IP section.
2
Click Settings > Paper Menu > Custom Types > select the custom
name you want to configure > select a paper or specialty media
type > Submit.
