Print defects guide

Repeating defects measurements

Match a set of repeating defects on a print job to the marks on one of the vertical lines. The line that best matches the defects

on the print job indicates which particular part is causing the defect.

For example, if the marks on the paper occur every 34.6 mm (1.4 in.), then the photoconductor unit needs to be replaced.

Note: Make sure the current selection in the printer for Scale to Fit in the PDF menu is set to No for the rulers to be printed at

the correct size.

43.9 mm

(1.7 in.)

Print defects guide

Page 1 of 2

34.6 mm

(1.4 in.)

94.2 mm

(3.71 in.)

Table of Contents

Do you have a question about the X548 and is the answer not in the manual?

Page 1 Print defects guide Page 1 of 2 Print defects guide Repeating defects measurements Match a set of repeating defects on a print job to the marks on one of the vertical lines. The line that best matches the defects on the print job indicates which particular part is causing the defect. For example, if the marks on the paper occur every 34.6 mm (1.4 in.), then the photoconductor unit needs to be replaced.
Page 2 Print defects guide Page 2 of 2 Change the transfer module. 37.7 mm 78.5 mm 55 mm (1.5 in.) (3.1 in.) (2.2 in.)
