Levelflex M FMP45 with PROFIBUS PA
Endress + Hauser
20 Process temperature:
Y Special version, to be specified
30 Probe:
A ..... mm, rope 4mm, 316
C .....inch, rope 1/6", 316
K .....mm, rod 16 mm, 316L
L ..... mm, coax, 316L
M .....inch, rod 16 mm, 316L
N ..... inch, coax, 316L
S *.....mm, rod 16 mm, 316L, 500 mm divisible
T *.....mm, rod 16 mm, 316L, 1000 divisible
U *.....inch, rod 16 mm, 316L, 20 in divisible
V *.....inch, rod 16 mm, 316L, 40 in divisible
Y Special version, to be specified
40 Process connection:
AFJ 2" 150lbs RF, 316/316L flange ANSI B16.5
AGJ 3" 150lbs RF, 316/316L flange ANSI B16.5
AHJ 4" 150lbs RF, 316/316L flange ANSI B16.5
ARJ 2" 300/600lbs RF, 316/316L flange ANSI B16.5
ASJ 3" 300/600lbs RF, 316/316L flange ANSI B16.5
ATJ 4" 300lbs RF, 316/316L flange ANSI B16.5
A1J 2" 1500lbs RF, 316/316L flange ANSI B16.5
A2J 3" 1500lbs RF, 316/316L flange ANSI B16.5
A3J 4" 600lbs RF, 316/316L flange ANSI B16.5
A4J 4" 900lbs RF, 316/316L flange ANSI B16.5
A5J 4" 1500lbs RF, 316/316L flange ANSI B16.5
CHJ DN100 PN10/16 B1, 316L flange EN1092-1 (DIN2527 C)
CRJ DN50 PN10-40 B1, 316L flange EN1092-1 (DIN2527 C)
CSJ DN80 PN10-40 B1, 316L flange EN1092-1 (DIN2527 C)
CTJ DN100 PN25/40 B1, 316L flange EN1092-1 (DIN2527 C)
C1J DN50 PN63 B2, 316L flange EN1092-1 (DIN2527 E)
C2J DN50 PN100 B2, 316L flange EN1092-1 (DIN2527 E)
C3J DN80 PN63 B2, 316L flange EN1092-1 (DIN2527 E)
C4J DN80 PN100 B2, 316L flange EN1092-1 (DIN2527 E)
C5J DN100 PN63 B2, 316L flange EN1092-1 (DIN2527 E)
C6J DN100 PN100 B2, 316L flange EN1092-1 (DIN2527 E)
KFJ 10K 50 RF, 316L flange JIS B2220
KGJ 10K 80 RF, 316L flange JIS B2220
KHJ 10K 100 RF, 316L flange JIS B2220
K3J 63K 50 RF, 316L flange JIS B2220
K4J 63K 80 RF, 316L flange JIS B2220
K5J 63K 100 RF, 316L flange JIS B2220
GGJ Thread ISO228 G1-1/2, 200bar, 316L
GJJ Thread ISO228 G1-1/2, 400bar, 316L, high pressure test
RGJ Thread ANSI NPT1-1/2, 200bar, 316L
RJJ Thread ANSI NPT1-1/2, 400bar, 316L, High pressure test
YY9 Special version, to be specified
50 Power supply; output:
B
D 2-wire; PROFIBUS PA
F
G 4-wire 90-250VAC; 4-20mA SIL HART
H 4-wire 10.5-32VDC; 4-20mA SIL HART
K 2-wire; 4-20mA HART, interface measurement
Y
60
70
2-wire; 4-20mA SIL HART
2-wire; FOUNDATION Fieldbus
Special version, to be specified
Operation:
1 W/o display, via communication
2 4-line display VU331, envelope curve display on site
3 Prepared for FHX40, remote display (accessory)
9 Special version, to be specified
Type of probe:
B *Compact, centering disc d=45 mm, 316L, pipe diameter DN50/2" + DN65/2-1/2"
C *Compact, centering disc d=75 mm, 316L, pipe diameter DN80/3" + DN100/4"
F *Remote, cable 3m, top, center d=45 mm, centering disk d=45 mm, 316L,
pipe diameter DN50/2" + DN65/2-1/2"
G *Remote, cable 3m, top, center d= 75 mm, centering disk d=75 mm, 316L,
pipe diameter DN80/3" + DN100/4"
Identification
9
