Loose Parts
Note: Use the chart below to verify that all parts have been shipped.
109-6792
Dealer Pack
Part #
Description
103-1309
Warranty Registration Form
Model Number
109-5200 – Fits 48" and 52" Quest decks
Parts List:
Item Part No.
Description
1
109-6768
Asm, Hood Bagger................................1
2
109-1939
Asm, Upper Tube ..................................1
3
109-6769
Asm, Lower Tube ..................................1
4
109-6107
Rod, Weight Lock..................................1
5
109-6494-03
Weight, Bagger 25#...............................1
6
104-8301
Nut, Nyloc 3/8-16 Flg ............................10
7
3274-94
Screw, Button Head 3/8-16 x 1..............2
8
109-6767
Asm, Bracket and Bumpers...................1
9
109-6092-03
Plate, Stiffener.......................................4
10
109-6795
Bolt, Carriage 3/8-16 x 5........................4
11
109-6093-03
Plate, Stiffener.......................................2
12
109-5379-03
Tube, Hitch............................................2
13
109-6094-03
Wld, Hitch..............................................1
14
3231-10
Bolt, Carriage 3/8-16 x 3........................ 4
▲
Blades are not included.
SETUP INSTRUCTIONS
109-6793
Part #
Qty
-----------
1
-----------
Recommended Bagger Blades
109-6391 – Fits 48" Quest decks
109-6392 – Fits 52" Quest decks
Qty.
Item Part No.
15
112-3994
16
104-7201
17
321-4
18
109-5383-01 Baffle, Discharge 52" ............................. 1
19
109-5387-03 Bkt, Boot Mount 52"............................... 1
109-6091-03 Bkt, Boot Mount 48"............................... 1
20
3230-23
3230-23
21
109-6771
22
104-8300
104-8300
23▲ 109-6391
109-6392
Figure 1
TM
QUEST
BAGGER
For Serial Nos. 670,000 and Higher
Literature Pack
Description
Manual, Operator's
Manual, Parts
Description
Asm, Bag .............................................. 2
Nut, Nyloc 1/4-20 Flg ............................ 2
Screw, 1/4-20 x 3/4 ............................... 2
Bolt, Carriage 5/16-18 x 3/4 48" ............. 1
Bolt, Carriage 5/16-18 x 3/4 52" ............. 3
Asm, Bagger Mount ............................... 1
Nut, Nyloc 5/16-18 Flg 48" ..................... 1
Nut, Nyloc 5/16-18 Flg 52" ..................... 3
Blade, High lift 48" ................................. 3
Blade, High lift 52" ................................. 3
109-6791 Rev. C
Qty
1
1
Qty.
Page 1 of 4
