Connecting the Control Panel
The BrewBuilt Control Panel has an included InkBird heating and
cooling controller and a 500 watt 12V DC power supply. It has
a tab welded to the top four screws and can be hung on a wall
or one of our optional stainless controller stands (CONP735 &
CONP736). On the bottom of the box there are 4 sockets. One
socket is for the power cord and it contains the power switch and
a fuse. There is a 3-pin connector for the heating element and
two 2-pin connectors for the cooling. Depending on what system
you have you may only need one cooling connector.
The power connectors are sealed with a water- tight cap. It is
best to leave the caps in place when not in use. The connectors
are polarity sensitive and will only go in one way. Once aligned
correctly they push in and rotate clockwise 1/4 turn to lock.
Setting Your Temperatures
The controller in your control panel is set to a standard ale
temperature settings and could ferment a California Ale out
of the box, but we are sure you bought this to explore other
fermentation temperatures as well. Setting the controller is very
easy.

FACTORY SETTINGS:

•tS = Set Point = 68
•CF = Celsius/Fahrenheit = F
To change the settings hold the S button down till tS is showing (about 5 seconds). Using the up and down arrows find
the setting you wish to check or change and press S. Set the new value with the up and down buttons and press S when
finished. When all settings are correct press the power button to return to normal operation.
NOTE: Changing from Celsius to Fahrenheit resets the other settings.
To set the Calibration offset, place the temperature sensor in a glass of ice water and stir till the reading is stable.
Subtract 32 from the reading and change the sign. If it reads 34, subtract 32 to get 2, change the sign and set the offset
to -2. This allows for changes in the resistance of the probe and connections.
• Do not pressurize without pressure relief valve in place
• Never open the lid clamp without completely depressurizing your conical first
• Never open any TC fitting without completely depressurizing your conical first
• Never remove the Flex Chamber without opening the bottom butterfly valve
and completely depressurizing your conical first
• Do not pick up conical when full
•CA = Calibration Offset = 0
•Pt = Compressor Delay = 0
•dS = Differential = 1
WARNINGS
FAILURE TO FOLLOW INSTRUCTIONS AND
WARNINGS CAN LEAD TO INJURY OR DEATH
POWER
SWITCH
FUSE
POWER
CORD
COOLING
ON
HEATING
POWER
ON
HEATER COOLING
SET DOWN
UP
