X1 UNI CONICAL ASSEMBLY & INSTRUCTION GUIDE For X1 Uni & X1 Uni + CONTENTS: PAGE 2–3........Cleaning, Testing, What’s Included PAGE 4......................Assembly PAGE 5.............How to Use The X1 Conical PAGE 6–8...........How to Use The X1 + Conical PAGE 8......................Warnings...
X1 UniX1 Uni + ITEM DESCRIPTION Congratulations on your purchase of 4" End Cap a BrewBuilt Conical! This guide will 4" TC Clamp walk you through assembling and 4" TC Gasket using your new conical fermenter. 1.5" Blow Off Barb...
Page 3
Additional Parts Included With X1 Uni + COOLSTIX FLEX CHAMBER NEOPRENE JACKET ™ PRESSURE PACK...
Page 4
THERMOWELL Place 1.5" TC Gasket and Thermowell into the open port in front of the conical just below the etched BrewBuilt Logo and fasten in place using 1.5" TC clamp. SAMPLE VALVE Place 1.5"...
Page 5
Basic Use the bottom. Another option is the BrewBuilt Flex Chamber FILLING — Your conical can be filled by dumping wort that connects to the bottom of the conical and allows you to collect and dump yeast and trub.
Page 6
Chamber to collect drips and un-clamp the Flex Chamber from the butterfly valve. The Flex Chamber is designed specifically for use with a BrewBuilt X1 conical. It attaches directly to the 2" FLUSHING THE FLEX CHAMBER WITH CO butterfly dump valve and can be used for removing...
Page 7
Keep in Pressure Fermentation Kit installed, there are three safety mind that your X1 Uni and Pressure Pack lid are rated at 15 psi and the PRV will start releasing pressure at that point.
Page 8
Neoprene jacket. A CoolStix ™ mates with a cold liquid source such as our BrewBuilt Max 2 or Max 4 Glycol Chiller. Your CoolStix comes ™ included with quick disconnects that stay sealed when disconnected to help eliminate messy leaks.
