7.5.3 Set Configuration Flags „of‟
Use this command to set or clear the Configuration Flags of the reader. In contrast to the EEPROM
registers, the settings of the „of‟ command are volatile, this means, they are taking effect on the
behavior of the reader at once and they are lost, when a reset occurs or the reader is powered down.
Command: 'of[FlagAddr][State]'
Answer
Answer Description
Data<CR><LF>
State of the modified flag
'R<CR><LF>'
Error: Flag out of range
Flag address Description
00h MultiTag
01h NewSerialMode
05h ExtendID
07h NoisyEnvironment
08h Reset Recovery Time Multiplier
11h ReqAExtendID
12h TagInfo
Examples
Command Description
of0001
Set MultiTag flag
of0501
Set ExtendID flag
of0700
Clear NoisyEnvironment flag
