Extendid; Baudrate Control Register (0Ch) - Elatec TWN3 Multi ISO Technical Manual

Character Transponder type
M ISO14443A, e.g. Mifare®
P PicoPass / ICLASS
S ISO14443B, e.g. SRIX4K
V ISO15693, e.g. I•Code SLI

5.4.5 ExtendID

If set, the unique serial number (UID) of the transponder is extended by a single prefix byte. This bit
has only effect for ISO14443A transponders.
This setting affects the commands continuous reading („c‟), single tag select („s‟) and multi tag select
(„m‟)
Default value: 0
Possible values for the prefix byte are:
Prefix Description
01h Cascade Level 1 transponder, e.g. Mifare® Classic
02h Cascade Level 2 transponder, e.g. Mifare® Ultralight
03h Cascade Level 3 transponder

5.5 Baudrate Control Register (0Ch)

The Baudrate control register defines the start-up baudrate of the reader. For baudrate values, refer to
the tables below:
Baudrate Control Register
Bit 7 Bit 6
RFU RFU
BS2 BS1
0 0
0 0
0 1
0 1
1 0
1 0
1 1
1 1
Elatec GmbH
Bit 5 Bit 4
RFU RFU
BS0 Resulting Baudrate
0 9600 bps (default)
1 19200 bps
0 38400 bps
1 57600 bps
0 115200 bps
1 reserved
0 reserved
1 reserved
Bit 3 Bit 2
RFU BS2
Bit 1 Bit 0
BS1 BS0
Page 12 of 65
