5. Register Set

The reader has several system flags customizing its behavior. The flags are stored non-volatile in its
EEPROM. It is recommended to keep all bits labeled RFU at their default state to guarantee further
compatibility.
Please consider that if any register is written, the reader needs a reset so that the changes may take
effect.

5.1 EEPROM Memory Organization

Register Access
00h ... 04h
RO
05h ... 09h
RO
0Ah R/W
0Bh R/W
0Ch R/W
0Dh R/W
0Eh R/W
0Fh R/W
10h R/W
11h R/W
12h R/W
13h R/W
14h R/W
15h R/W
16h R/W
17h R/W
18h R/W
19h R/W
1Ah R/W
1Bh R/W
1Ch ... 1Fh
R/W
20h ... DFh
R/W
E0h ... EFh
R/W
F0h ... FDh
R/W
FEh R/W
FFh R/W
Elatec GmbH
Default value Description
XXh Unique device ID
00h Internal use
01h Station ID
41h Protocol Configuration Register 1
00h Baudrate Control Register
20h RFU, never change this register
7Fh Operation mode Register 1
0Ah RFU, never change this register
00h Internal use
00h Internal use
00h Internal use
00h Protocol Configuration Register 2
0Ah Reset Off Time
25h Reset Recovery Time
00h Application Family Identifier AFI
10h Internal use
50h Internal use
10h Internal use
20h Internal use
00h Protocol Configuration Register 3
00h Internal use
FFh RFU, never change this register
00h Installation Identifier
FFh RFU, never change this register
01h Operation Mode Register 2
22h Beep tone and length (Nano Module Multi ISO only)
