  • Page 1 DS-C555-4X3 46" - 55" 1200 lb (117 - 140 cm) (545 kg) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 2 WARNING ENG - Do not begin to install product until you have read and understood the instructions and warnings contained in this user guide. Always use an assistant or mechanical lifting equipment to safely lift and position equipment. This product must be installed onto flat, hard, level surface to prevent tipping. Use with heavier displays may result in instability causing tip over resulting in death or serious injury.
  • Page 3 This page intentionally left blank. 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 4 Parts (Before beginning, make sure you have all parts shown below). Parts List Description Part # caster, 5" swivel 600-0026 caster support 145-T1799 cover 145-T1809 base leg 145-T1767 horizontal leg support 145-T1785 base support tube 145-T1812 base support 560-T1261 vertical leg support 146-T1131 extension 145-T1778...
  • Page 5 N ( 6 ) P ( 1 ) O ( 1 ) dual cross computer shelf computer cover support S ( 3 ) bracket, 4x2 M ( 6 ) Q ( 3 ) configuration vertical support extension bracket R ( 6 ) adaptor cord bracket...

  • Page 6: Side View

    U (4) Do not fully tighten hardware V (2) U (2) SIDE VIEW 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 7 V (4) V (4) U (4) V (4) U (4) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 8 TIGHTEN Flush edges CONNECTING HARDWARE Casters must be flush to end of horizontal leg support. SIDE VIEW Y (2) Do not fully tighten hardware U (4) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 9 TIGHTEN CONNECTING HARDWARE TIGHTEN CONNECTING HARDWARE 2015-06-24 #:009-9118-6 (2019-09-04)

  • Page 10: Top View

    Do not fully tighten hardware U (4) Y (2) TOP VIEW TIGHTEN CONNECTING HARDWARE I (3) Q (3) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 11 LOCK WHEELS TIGHTEN CONNECTING HARDWARE 1/8" 1/8" (3mm) (3mm) V (4) U (6) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 12 Use metric formula below and diagram to the right to determine hole pattern required for center vertical support bracket. Repeat (x2). All dimensions are metric. BACK OF DISPLAY Use the outside mounting holes when… a x 4 > 4368mm and a x 3 + b < 4318mm V (8) U (12) Use the inside mounting holes when…...
  • Page 13 M (6) S (3) TIGHTEN CONNECTING HARDWARE 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 14 11-1 TIGHTEN CONNECTING HARDWARE N (2) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 15 11-2 TIGHTEN CONNECTING N (2) HARDWARE 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 16 11-3 TIGHTEN CONNECTING HARDWARE N (2) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 17 V (8) U (8) U (2) TIGHTEN CONNECTING HARDWARE V (2) J (4) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 18 13-1 Center adaptor brackets vertically on back of screen. 13-2 BB CC 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 19 14-1 "LOCKED" POSITION Must hang displays on bottom row first; Secure pin in "locked" position. 14-2 "LOCKED" POSITION Must hang displays on middle row second; Secure pin in "locked" position. 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 20 14-3 "LOCKED" POSITION Must hang displays on top row last; Secure pin in "locked" position. 14-4 Optional: Insert M5 x 10mm type-F socket pin screws (X) to lock latches. "LOCKED" POSITION 2015-06-24 #:009-9118-6 (2019-09-04)

  • Page 21: Rotate Right

    Display adjustment TILT FORWARD SIDE SIDE SIDE TILT BACKWARD TILT RIGHT TILT LEFT SIDE DOWN ROTATE LEFT ROTATE RIGHT 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 22 TIGHTEN CONNECTING HARDWARE R (6) T (6) TOP VIEW Optional: Unlock wheels to move cart to desired location; Lock wheels before hanging screens. LOCK WHEELS 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 23 X (24) C (6) 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 24 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 25 19-1 1/8" (3mm) X (2) 19-2 TIGHTEN CONNECTING HARDWARE 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 26 Route cables through cord brackets. 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 27 21-1 Display removal Pull down on bracket cords and hold. Swing screen away from cart and lift to remove. 21-2 "UNLOCKED" POSITION Remove displays from top row first. 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 28 21-3 "UNLOCKED" POSITION Remove displays from middle row second. 21-4 "UNLOCKED" POSITION Remove displays from bottom row last. 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 29 This page intentionally left blank. 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 30 This page intentionally left blank. 2015-06-24 #:009-9118-6 (2019-09-04)
  • Page 31 This page intentionally left blank. 2015-06-24 #:009-9118-6 (2019-09-04)

  • Page 32: Limited Five-Year Warranty

    (from date of the original installation of the product). At its option, Peerless-AV will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
