COMPATIBILITY
MOD POLES
MOD-P100(-B), MOD-P150(-B), MOD-P200(-B),
MOD-P300(-B)
*MOD COLUMNS REQUIRE MOD-ATA
ADAPTER
DST995
95"
MAX
(241 cm)
COLUMNS
EXT006 through EXT110,
AEC012018 through AEC1012,
ALU0090012 through ALU1012,
ADD series
1
225 lb
(102 kg)
ACCESSORIES
ACC-V800X
2013-09-16 #:145-9028-4 (2013-10-31)

Advertisement

loading
Need help?

Need help?

Do you have a question about the DST995 and is the answer not in the manual?

Questions and answers

Related Manuals for peerless-AV DST995

Summary of Contents for peerless-AV DST995

  • Page 1 DST995 95" 225 lb (241 cm) (102 kg) COMPATIBILITY MOD POLES COLUMNS ACCESSORIES MOD-P100(-B), MOD-P150(-B), MOD-P200(-B), EXT006 through EXT110, ACC-V800X MOD-P300(-B) AEC012018 through AEC1012, *MOD COLUMNS REQUIRE MOD-ATA ALU0090012 through ALU1012, ADAPTER ADD series 2013-09-16 #:145-9028-4 (2013-10-31)
  • Page 2 This page intentionally left blank. 2013-09-16 #:145-9028-4 (2013-10-31)
  • Page 3 WARNING Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

  • Page 4: Parts List

    Parts List Description Part # component box 145-1782 rear cover 145-1534 pinch bracket 130-1073 yaw bracket 130-1500 adapter bracket 145-1780 snap bushing 590-1149 fiber washer 540-9432 retaining collar 1800-375 1/4" SAE flat washer 540-9440 M5 x 55mm socket pin screw 520-1193 M5x 10mm socket pin screw 520-1164...
  • Page 5 F ( 2 ) G ( 1 ) snap fiber washer bushing I ( 8 ) J ( 2 ) K ( 9 ) 1/4" washer M5 x 55mm M5 x 10mm H ( 1 ) L ( 8 ) M ( 4 ) retaining collar...
  • Page 6 Install EXT, ADD, AEC, or ALU series extension column (sold separately). See accompanying instruction. Install MOD-ATA threaded adapteradapter. F (2) 2013-09-16 #:145-9028-4 (2013-10-31)
  • Page 7 MOD-ATA 2013-09-16 #:145-9028-4 (2013-10-31)
  • Page 8 K (2) J (2) N (2) ⅛" ⅛" ⅛" 2013-09-16 #:145-9028-4 (2013-10-31)
  • Page 9 11.81" (300mm) 3.94" 15.75" 11.81" 7.87" (100mm) (400mm) (300mm) (200mm) 7.87" (200mm) 15.75" (400mm) ACC-V800X ACCESSORY SOLD SEPARATELY 31.5" (800mm) 23.62" (600mm) PORTRAIT LANDSCAPE 2013-09-16 #:145-9028-4 (2013-10-31)
  • Page 10 If screw (M) bottoms out, use one or two washers (I) in each mounting hole position. L, M 10º 5º 15º Tighten 2013-09-16 #:145-9028-4 (2013-10-31)
  • Page 11 install media player is space provided before attaching rear cover. Tighten Tighten 2013-09-16 #:145-9028-4 (2013-10-31)

  • Page 12: Limited Five-Year Warranty

    LIMITED FIVE-YEAR WARRANTY Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless products will be free from defects in material and ® workmanship, under normal use, for a period of five years from the date of purchase by the original end-user (but in no case longer than six years after the date of the product's manufacture).
