- Page 1 ACC-MBC 40" - 48" 300 lb (102 - 122 cm) (136 kg) Compatible with: DS-MBY942L-2X1 DS-MBY942L-3X1 DS-MBY947-2X1 DS-MBY947-3X1 2015-02-10 #:126-9049...
- Page 2 WARNING ENG - This product is designed to be installed on wood joist/beam or solid concrete ceilings. Hardware is included for wood joist/beam and solid concrete installation. Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
- Page 3 Parts (Before beginning, make sure you have all parts shown below). Parts List Description Part # ACC frame 146-1212 support bracket 146-1053 hex head screw 520-1321 1/4-20 x 1/2" phillips screw 510-9108 support bracket ACC frame C (24) D (2) hex head screw 1/4-20 x 1/2"...
- Page 4 B(4) ENG Main frame (sold separately) 3/8" (10mm) C(16) 2015-02-10 #:126-9049...
- Page 5 7/16" (11mm) ENG Loosen, adjust, tighten. ENG Extension columns (sold separately) ENG Main post (sold separately) 2015-02-10 #:126-9049...
- Page 6 ENG Large washer ENG Retaining collar (sold separately) (sold separately) SLOT ENG M5 x 10mm ENG Align slot of extension column socket pin screw ENG 4mm allen wrench (sold separtately) ENG #10 x 1/2" phillips screw (sold separately) 2015-02-10 #:126-9049...
- Page 7 D(2) 3/8" (10mm) C (8) 2015-02-10 #:126-9049...
- Page 8 This warranty gives specifi c legal rights, and you may also have other rights which vary from state to state. Peerless-AV Peerless-AV Europe Peerless-AV de Mexico 2300 White Oak Circle Unit 3 Watford Interchange, Ave de las Industrias 413...
